A Method to Estimate Voltage Sag Caused by Transformer Excitation Inrush Current

Abstract:

Due to excitation inrush current, no-load transformer accesses system can cause different degree of voltage sag. Therefore presents a method to estimate voltage sag caused by closing no-load transformer. Firstly, accord to the point of saturation magnetic flux and transformer core general single value curve equation to establish general nonlinear magnetization curve. Use the linear features of saturated magnetization curve segment to estimate the maximum inrush current and calculate the maximum depth of voltage sag. According to the magnetic flux decay time to estimate the duration of voltage sag. Simulate closing no-load transformer in a 10kV distribution network, and compare the simulated result with the calculated result. The results show that the proposed method is validity and accuracy.

• Periodical: Applied Mechanics and Materials (Volumes 494-495)
• Pages: 1491-1495
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.494-495.1491
• Online since: February 2014
• Authors: Ai Qiang Pan*, Ling Luo, Jia Pei Jin, Xiao Qing Wu
• Keywords: No-Load Transformer, Transformer Inrush Current, Voltage Sag

References

[1] Zhu Yi: Influence and Control of Voltage Dip to Sensitive Electrical Equipment [J]. Electrical Engineering, vol. 7 (2007), pp.76-81.

[2] Xiao Xiangning: The power quality analysis and control, Beijing: China electric power press, 2002(in Chinese).

[3] Xiao Xiangning, Tao Shun: Voltage Sags Types Under Different Grounding Modes of Neutral and Their Propagation Part One [J]. Transactions of China Electro technical Society, vol. 22(2007), pp.143-147, 153(in Chinese).

[4] Math H J Bollen: Understanding power quality problems, voltage sags and interruption, in New York: IEEE Press，(2000).

[5] Hazlie Mokhlis，Haiyu Li: Non-linear representation of voltage sag profiles for fault location in distribution networks [J]. Electrical Power and Energy Systems, vol. 33, pp.124-130.

DOI: 10.1016/j.ijepes.2010.06.020

[6] Lin Jiming, Wang Xiaogang, Ban Liangeng: Resonance overvoltage caused by energizing no-load transformer in 1000kV AC transmission system [J]. Power System Technology, vol. 31 (2007), pp.5-7(in Chinese).

[7] Jiang Weiping，Zhu Yiying，Wu Yani，et al．: Analysis on measured and calculated results of the switching surge in 750 kV transmission pilot projects [J]. Power System Technology，vol. 30 (2006) ：9-12 (in Chinese).

[8] Weng Hanli, Lin Xiangning: Analysis of complex electromagnetic transient leading to the mal-operation of power transformer differential protection [J]. Proceedings of the CSEE, vol. 29 (2009), pp.65-66(in Chinese).

[9] Li Xiaoping, Wen Xishan, Chen Cixuan: Study of Nonlinear Characteristic Curve for the Core of Transformer with Magnetic Coupling [J]. High Voltage Engineering, vol. 31 (2005), pp.9-11(in Chinese).

DOI: 10.1109/emczur.2006.214913
