Dynamic Characteristics Analysis for 1000kV UHV Steel Tubular Tower under Seismic Loading

Abstract:

In this paper, the dynamic characteristics of a 1000kV UHV steel tubular tower with double circuit transmission lines on the same tower are analyzed under seismic loading with 8 degrees fortification intensity. Firstly, the finite element model of the tower and simulation of the earthquake are built in ANSYS finite element software. The dynamic characteristics of steel tube tower under Seismic Loads, such as the time-domain curves of displacement, velocity and force of UHV steel tower under Seismic Loads are obtained. The impact of 1000kV UHV transmission tower under nonlinear vibration of simplified conductor model is studied. The results can help to understand the damage forms of UHV steel tower under earthquake, to improve the capabilities to resist earthquake loads and severe damage of environmental loads under various field conditions for UHV steel tower.

• Periodical: Applied Mechanics and Materials (Volumes 494-495)
• Pages: 1815-1819
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.494-495.1815
• Online since: February 2014
• Authors: Li Qiang An*, Yu Chu Liu, Bing Zhang
• Keywords: 1000KV UHV, 8 Degree Seismic Fortification Intensity, Dynamic Characteristic, Steel Tube Tower

References

[1] Ozono S，Maeda J． In plane dynamic interaction between a tower and conductors at lower frequencies. Engineer Structure. Vol. 14, No. 4, (1992).

DOI: 10.1016/0141-0296(92)90009-f

[2] Albermani F, Kitipornchai S. Numerical simulation of structural behavior of transmission towers．Thin-Walled structures. Vol. 41, No. 2-3, (2003).

DOI: 10.1016/s0263-8231(02)00085-x

[3] Hongnan Li, Wenlong Shi, Lianguang Jia. Limitations of Effects of Lines on In_plane Vibration of Transmission Towers and Simplified Seismic Calculation Method[J]. Journal of Vibration and Shock. Vol. 23, No. 2, 2004(In Chinese).

[4] Hongnan Li, Qianxin Wang. Dynamic Characteristics of Long-span Transmission Lines and Their Supporting Towers. China Civil Engineering Journal. Vol. 30, No. 5, 1997(In Chinese).

[5] Hongnan Li, Dazhu Hu, Lianzhuang Huang. Plastic Limit Analysis of the Transmission Tower System Subjected to Earthquake Action . Proceedings of the CSEE. Vol. 26, No. 24, Dec. 2006(In Chinese).

[6] Hongnan Li, Wenlong Shi, Suyan Wang. Simplified Seismic Calculation Method of the Coupled System of Transmission Lines and Their Supporting Tower[J] . Special Structures, 2002, 19(3): 58-61(In Chinese).

[7] Qiang Xie, Jie Bai, Songtao Xue. Shaking Table Tests on 1000 kV UHV AC Double Circuit Transmission Tower-conductor Coupling Systems. Proceedings of the CSEE. Vol. 33, No. 7, Mar. 5, 2013(In Chinese).
