Design and Strength Analysis of the Wheelchair Switching Mechanism

Abstract:

Based on studying the existing electric wheelchairs for disabled are not well adapted to a variety of road conditions, broken through the structure of traditional wheelchairs, a design proposal that can make electric wheelchair achieve the function of climbing stairs and walking was putted forward and a novel mechanism was designed. The mechanism can make the crawler chassis and the wheels of wheelchair switch when needed, and make the wheelchair travel freely and flexible on the ground or on the stairs. The finite element model of the mechanism was built, and the strength analysis was carried out. The strength analysis provide the theoretical basis for the prototype manufacture.

• Periodical: Applied Mechanics and Materials (Volumes 494-495)
• Pages: 337-340
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.494-495.337
• Online since: February 2014
• Authors: Yu Wen Li*, Jian Kang Wei, Jin Zhang
• Keywords: Climbing Stairs, Mechanism Design, Strength Analysis, Switching Mechanism

References

[1] Yu-shao WU. Blue book of aging: China report of the development on aging cause(2013). Social sciences academic press(china): 2-3.

[2] National Bureau of Statistics of China, the team of the second national sample survey on disability. The main date report of the second national sample survey on disability. Disability in China, 2006(12): 5.

[3] Hai-wei Gong, Jian-guo Zhang, He-rong Liu, Xian-zhong Zhu. Mechanism Design and Analysis of a Multifunctional Device for Lower Limb Disabilities. Machinery Design & Manufacture, 2012, 11: 58-60.

[4] Burgar C G, LumSL, Shor PC, et al. Development of robots for rehabilitations therapy: the Palo Alto VA/Stanford experience. Journal of Rehabilitation Research and Development, 2000, 37(6): 663-673.

[5] Hong-xin Wang, Shu-jun Du, Xu Yang. Mechanism Design on Erectile Walking Assistant Wheelchair. Journal of Mechanical Transmission, 2010, 34(5): 45-48.
