Rapid Calculation of Trimming Line for Panel Flanging Forming

Abstract:

Calculating the trimming line is an important step for the panel flanging. In this paper, we use the one step inverse finite element method to calculate the trimming line for auto panels flanging, the finite element model of flanging forming is established and completed the iterative solution of the equation, using the reverse deformation method to establish the linear elastic balance equation to solve the iterative initial value, and thus get the trimming line accurately and rapidly. Through the calculation of the trimming line of some flange part verified the effectiveness of the algorithm.

• Periodical: Applied Mechanics and Materials (Volumes 494-495)
• Pages: 751-755
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.494-495.751
• Online since: February 2014
• Authors: Chi Di*
• Keywords: Auto Panels, Flanging Forming, Inverse Forming, Trimming Line

References

[1] Hu Ping, Li Dayong, Li Yunxing. Analytical Model of Stretch and Shrink Flanging. Int. J. Mach. Tools and Manufacture, 2003, 43: 1367-1373.

DOI: 10.1016/s0890-6955(03)00150-0

[2] WANG Wei, LIU Yu-qi, etc. Development of trimming line unfolding and flanging forming simulation system based on Pro/E platform, Forging & Stamping, 2010, 35(6): 45-48.

[3] HAO Xiao-zhong, ZHOU Xin-quan, BAO Yi-dong. Prediction and Optimum Design of 3-D Trimming Line Based on One-step Inverse Analysis, Machine Building & automation, 2009，38(2): 26-28.

[4] LI Da-yong, FAN Hai-yan, WANG Yu-guo. A Simple Method Algorithm for Trim-line Prediction in Flanging Operations, Automobile Technology & Material, 2002，23(5)：11-14.

[5] Seung Ho Kim, Se Ho Kim. Finite element inverse analysis for the design of intermediate dies in multi-stage deep-drawing processes with large aspect ratio. Journal of Materials Processing Technology, 2001, 113: 779-785.

DOI: 10.1016/s0924-0136(01)00660-4

[6] Batoz Jean-Louis, Guo Yingqiao, Mercier Frederic. The inverse approach with simple triangular shell elements for large strain predictions of sheet metal forming parts. Engineering Computations, 1998, 15(7): 864-892.

DOI: 10.1108/02644409810236894

[7] Jingxin Na, Jian Jiao, Yakun Yan, Haipeng Liu. A membrane element model with bending modification for one step inverse method. Acta Mechanica Solida Sinica, 2011, 24(3): 282-288.

DOI: 10.1016/s0894-9166(11)60029-3

[8] Baojun Li, Xiangkui Zhang, Ping Zhou, Ping Hu. Mesh parameterization based on one-step inverse forming. Computer-Aided Design, 2010, 42(7): 633-640.

DOI: 10.1016/j.cad.2010.04.003

[9] Ying Huang, Yi-Ping Chen, Ru-Xu Du. A new approach to solve key issues in multi-step inverse finite-element method in sheet metal stamping. International Journal of Mechanical Sciences, 2006, 48(6): 591-600.

DOI: 10.1016/j.ijmecsci.2006.01.007
