Elasto-Plastic Fracture Analysis of Finite-Width Cracked Stiffened Plate

Abstract:

Thispaper adopts the crack line-field method to analyze finite-width stiffenedplates with central through I-type crack under uniaxial tensile loading. Themethod completely abandons the small scale yield hypothesis. The plastic stressand strain fields at crack tips and the plastic-zone length can be accurately determinedby combining with equivalent shear stress of Westergaard stress function in theposition of stiffener. It can be seen from the illustrative example that theresults of the paper agree well with those by finite element method.

• Periodical: Applied Mechanics and Materials (Volumes 496-500)
• Pages: 1052-1057
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.496-500.1052
• Online since: January 2014
• Authors: Jun Lin Deng, Ping Yang, Qin Dong, Xiang Yan
• Keywords: Elasto-Plasticanalysis, Line-Field Analysis, Stiffened Plate, Westergaard Stress Function

References

[1] Yi Z J. The most recent solutions of near crack line fields for mode iii cracks. Engineering Fracture Mechanics. 1994, (47): 147-155.

DOI: 10.1016/0013-7944(94)90245-3

[2] Yi Z J, Wang S J, Wang X J. Precise solutions of elastic-plastic crack line fields for cracked plate loaded by anti-plane point forces. Engineering Fracture Mechanics, 1997, 50: 75-83.

DOI: 10.1016/s0013-7944(97)00003-9

[3] Achenbach J D, Li Z L. Plane stress crack line fields for crack growth in an elastic-Perfectly plastic material, Engineering Fracture Mechanics, 1984, (20): 534-544.

DOI: 10.1016/0013-7944(84)90058-4

[4] Yi Z J. Precise solutions of elastic-plastic crack line fields for cracked plate loaded by anti-plane point forces. Engineering Fracture Mechanics. 1997, (1): 57-83.

DOI: 10.1016/s0013-7944(97)00003-9

[5] Guo Qianxin, Li Kerong. Plastic deformation ahead of a plane stress tensile crack growth in an elastic-Perfectly Plastic solid, Engineering Fracture Mechanics. 1987, (28): 139-146.

DOI: 10.1016/0013-7944(87)90209-8

[6] Yi Z H, Wang S J. Exact Solutions of near crack line fields for model I crack under plane stress condition in an elastic-plastic solid. Applied Mathematics and Mechanics. 1996, (4): 336-342. (in Chinese).

DOI: 10.1007/bf00193798

[7] Hult J A, McClintoek F A. Elastic-plastic stress and strain distribution around sharp notches under repeated shear. Proc. 9th. Int. Congr. APPl. Mech, 1957, (8): 51-58.

[8] Calvin Rans, Riccardo Rodi, René Alderliesten. Analytical prediction of Mode I stress intensity factors for cracked panels containing bonded stiffeners. Engineering Fracture Mechanics, 2013, (97): 12-29.

DOI: 10.1016/j.engfracmech.2012.11.001

[9] Vlieger H. The residual strength characteristics of stiffened panels containing fatigue cracks. Engineering Fracture Mechanics, 1973, (5): 47-70.

DOI: 10.1016/0013-7944(73)90033-7
