An Improved VSVPWM Strategy of Considering Neutral-Point Potential Balancing in Three-Level NPC Converter

Abstract:

Neutral-point (NP)-clamped three-level converter is a widely used topology in the research fields of the multilevel converters, which suffers from the NP voltage drift as its main technical drawback. In theory, it is based on the fact that the virtual space vector modulation approach could completely control the balance of neutral-point potential, so this paper introduces a improved control strategy of neutral-point potential balancing in three-level converter, which combines the space vector modulation approach based on virtual vectors with the algorithm of modifying small vectors pairs distribution time accurately. Relative to the traditional proposed algorithm of setting voltage tolerance range to modify small vectors pairs distribution time,the performance of algorithm of capacitor charge balancing is better and its accuracy of control is more precise. The feasibility of the proposed control approach has been verified via experiment results.

• Periodical: Applied Mechanics and Materials (Volumes 496-500)
• Pages: 1079-1083
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.496-500.1079
• Online since: January 2014
• Authors: Shi Weng Gui*, Lu Wang, Sheng Hua Huang
• Keywords: Capacitor Charge Balancing, Neutral-Point (NP)-Clamped Three-Level Converter, Space Vector Pulse Width Modulation, Virtual Space Vector, VSVPWM

References

[1] J. Rodriguez, S. Bernet, B. Wu, J. O. Pontt and S. Kouro, Multilevel voltage source converter for industrial medium voltage drives, IEEE Transactions on Industrial Electronics, Vol. 54, 2007, pp.2930-2945.

DOI: 10.1109/tie.2007.907044

[2] A. Nabae, I. Takahashi, and H. Akagi, A new neutral-point clamped PWM inverter, IEEE Trans. Ind. Appl., vol. IA-17, p.518–523, Sep. /Oct. (1981).

DOI: 10.1109/tia.1981.4503992

[3] S. Busquets-Monge, J. Bordonau, D. Boroyevich, and S. Somavilla, The nearest three virtual space vector PWM—A modulation for the comprehensive neutral-point balancing in the three-level NPC inverter, IEEE Power Electron. Lett., vol. 2, no. 1, p.11–15, Mar. (2004).

DOI: 10.1109/lpel.2004.828445

[4] S.B. Monge, S. Somavilla, J. Bordonau and D. Boroyevich, Capacitor Voltage Balance for the Neutral-Point-Clamped Converter using the Virtual Space Vector Concept With Optimized Spectral Performance, IEEE Power Electron. Lett., vol. 22, no. 4, p.1128–1135, July. (2007).

DOI: 10.1109/tpel.2007.900547

[5] Changliang Xia, Hongjun Shao, Yun Zhang, and Xiangning He, Adjustable Proportional Hybrid SVPWM Strategy for Neutral-Point-Clamped Three-Level Inverters, IEEE Trans. Ind. Appl., vol. 60, no. 10, p.4234–4241, Oct. (2013).

DOI: 10.1109/tie.2012.2213558

[6] Song Wenxiang, Chen Guocheng, Wu Hui, et al. A novel SVPWM strategy and its implementation considering neutral-point potential balancing for three-level NPC inverter[J], Proceedings of the CSEE, 2006, 26(12): pp.95-100.

DOI: 10.1007/s11741-006-0105-7

[7] Jiang Weidong, Wang Qunjing, Shi Xiaofeng, et al. Low frequency oscillation of neutral point voltage of neutral point-clamped three-level VSI under SVPWM control [J], Proceedings of the CSEE, 2009, 29(3): pp.49-55.

DOI: 10.1109/icems12746.2007.4412144

[8] Ramkrishan Maheshwari, Stig Munk-Nielsen, and Sergio Busquets-Monge, Design of Neutral-Point Voltage Controller of a Three-Level NPC Inverter With Small DC-Link Capacitors, IEEE Transactions on Industrial Electronics, Vol. 60, No. 5, pp.1861-1871, May. (2013).

DOI: 10.1109/tie.2012.2202352
