The Variable PWM Frequency Control Research for the Motor in Wheel

Abstract:

According to the characteristics that the motor in wheel is insensitivity of torque ripple, the impact of reducing PWM frequency on motor control is studied, and the phenomenon that the PWM frequency is limited by the lag angle of motor commutation. Then a variable PWM frequency control strategy according to rotate speed is proposed. Based on Simulink, the motor control model is built and the control strategy is verified by simulation. The result shows that the variable PWM frequency control significantly improves the performance of motor at low speed, with little toque ripple increased.

• Periodical: Applied Mechanics and Materials (Volumes 496-500)
• Pages: 1352-1355
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.496-500.1352
• Online since: January 2014
• Authors: Chuan Xue Song, Si Lun Peng*, Shi Xin Song, Jian Hua Li, Zhu'an Zheng
• Keywords: Motor Controller, Motor in Wheel, Simulink, Variable PWM Frequency

References

[1] Konghirun, Mongko: IEEE TENCON 2004 - 2004 IEEE Region 10 Conference. Vol. D (2004), pp.167-170.

[2] Maswood, Ali. I.: 2008 IEEE 2nd International Power and Energy Conference Vol. 1 (2008), pp.609-613.

[3] Wang Xiao-Yuan, Chen Jing and Wang Ping-Xin: Shenyang Gongye Daxue Xuebao Vol. 34 (2012), pp.247-252.

[4] Cao Jianrong, Yu Lie, Xie Youbai: Journal of Xi'an Jiaotong University Vol. 34 (2000), pp.71-75.

[5] He Qiang, Li Bin, Ge Yong: J Chongqing Technol Business Univ. (Nat Sci Ed) Vol. 29(2012), pp.71-78.
