Modal Analysis of Magnetic Suspended Control Moment Gyroscope

Abstract:

3D finite element models of magnetic suspended control moment gyroscope structure are established by general finite element analysis software. Initial modal analysis scheme of the MS-CMG structure, in which the frame and gyro-chamber are analyzed separately, is described. A new modal analysis scheme that the MS-CMG is analyzed as a whole structure is presented. The connection between the gyro-chamber and frame is realized by defining a revolution pairs. The numerical predictions from two modal analysis schemes show obvious difference. The new scheme is more reliable since it simulates the real wok status of MS-CMG.

• Periodical: Applied Mechanics and Materials (Volumes 50-51)
• Pages: 59-62
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.50-51.59
• Online since: February 2011
• Authors: Wei Zhao, Li Bin Zhao, Jian Yu Zhang, Bang Cheng Han
• Keywords: ANSYS, Control Moment Gyroscope, Finite Element, Modal Analysis

References

[1] B. Wie, K.W. Byun, V.W. Warren, D. Geller, D. Long and J. Sunkel: Journal of Guidance, Control, and Dynamics Vol. 12(5) (1989), p.714.

DOI: 10.2514/3.20466

[2] Tang Liang and Chen Yiqing: Acta Astronautica Vol. 65 (2009), p.1506.

[3] Han Bangcheng, Hu Gang and Fang Jiancheng: Optics and Precision Engineering Vol. 14(4) (2006), p.662.

[4] Han Bangcheng, Zhang Shuna, Fang Jiancheng and Zhao Libin: Journal of System Simulation Vol. 20(3) (2008), p.763.

[5] Feng Hongwei and Fang Jiancheng: Journal of Chinese Inertial Technology Vol. 13(1) (2005), p.72.

[6] ANSYS Element Reference, Release 11. 0, ANSYS Inc, (2007).

[7] Yang Guojun, Xu Yang, Shi Zhengang and Gu Huidong: Nuclear Engineering and Design Vol. 237(2007), p.1363.

DOI: 10.1016/j.nucengdes.2006.09.040

[8] Y.A. Khulief and M.A. Mohiuddin: Finite Elements in Analysis and Design Vol. 26 (1997), p.41.
