The Applicable Development of Steel-Construction Process Dynamic Visual Simulation Software

Abstract:

In this paper, steel-trussed bridging method is combined with the whole process of the construction-management project with an aim to develop a visual simulation software, whose database requires a three-dimensional model of dynamic visual simulation. This application can quickly realize the rapid construction of various types of data and retrieval data-management digitization. The software system achieves the management visualization of various types of integrated data, which are easy to use, intuitive to understand. The system is suitable for all types of steel works automation and some refinement of modern construction project management.

• Periodical: Applied Mechanics and Materials (Volumes 501-504)
• Pages: 2567-2570
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.501-504.2567
• Online since: January 2014
• Authors: Hua Jiang*, Liang Tong, Yang Qiuye Gao
• Keywords: Bridge, Steel Structure Construction Process, Visualization Management Software

References

[1] Wei Qun, Peng Chengshan, Jiang Hua et al. Study onsimulation technology during erection of steel truss girder(report). The steel structure and the North China Institute of water conservancy and Hydropower Engineering Research Institute. 2008 7.

[2] Wei Qun. Study on CIS/2 steel structure database and accesstechnology, Aus-pic Canada Research Center. (2003).

[3] Jiang Hua, Wei Qun, Peng movement. The Baling River large suspension bridge with steel truss beam installation construction of new technology of [J]. North China Institute of water conservancy and hydroelectric power, 2010, 31 (1): 37-40.

[4] Ma Anqing, Dan Hongxian, Jia Yonggang, et al. Shandongprovince highway engineering geological information querysystem of VB based [J]. remote sensing technology and should be based on, 2005: 20 (6).

[5] Wei Qun, Jiang Hua, Peng Yundong et al. Large scale steel truss suspension bridge joint stiffness of bridge impact force. The highway. 2009 (3): 29-33.

[6] Wei Lu double arch structure of 3D modeling software key technology research of [D]. University of Electronic Science and technology of 2006 master's thesis.

[7] Jiang Hua, Wei Qun, Jiao Tao et al. Analysis of the seismic performance of opening in beam web steel frame. Journal of Henan Polytechnic University, 2008, Vo1. 27: 333-338.
