Based on PLC Control of Double Constant Pressure No Tower Water Supply System Design

Abstract:

In view of the traditional double motor constant pressure water supply system without tower in the operation process of the problem of short service life, the design of a new type of dual voltage no tower water supply control system. The control system uses PLC, soft starter and frequency converter technology, the soft starter can make the motor to realize soft start and soft stop, no impact on the motor, can extend the service life of the motor, avoid pumping station "door" damage, reduce repair costs and repair work. The running results show that, after the reformation of water supply system can save more than 21% energy, but also improve the quality and reliability of the water supply.

• Periodical: Applied Mechanics and Materials (Volumes 511-512)
• Pages: 1002-1007
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.511-512.1002
• Online since: February 2014
• Authors: Lie Zhun Wang
• Keywords: Double Constant Pressure, Frequency Converter, No Tower Water Supply, PLC

References

[1] Yang Youping, Weng Huihui. Realization of piecewise constant pressure water supply system control with PLC [J]. Electrical engineering technology, Vol. 39, 2010 (9) , pp.46-48.

[2] Li Fangyuan. Inverter control technology [M]. Beijing: Electronic Industry Press, (2010).

[3] Jiang Suxia etc. Design and simulation constant pressure water supply control system based on PLC[J]. Journal of Zhengzhou University of Light Industry (NATURAL SCIENCE EDITION), Vol. 26, 2011 (1) , pp.64-66.

[4] Deng song. Comprehensive application of programmable controller [M]. Beijing: Mechanical Industry Press, (2010).

[5] Mitsubishi Co. Mitsubishi inverter FR-E700 manual (application) [M]. Mitsubishi Co, (2008).

[6] Wang Renxiang. Common low-voltage apparatus and its control technology [M]. Beijing: Mechanical Industry Press, (2007).

[7] Li Liangren. The frequency converter technology and application [M]. 2 edition. Beijing: Electronic Industry Press, (2009).

[8] Zhou Li. The control system design fuzzy variable frequency constant pressure water supply based on PLC[J] . Mechanical and electrical engineering, Vol. 22, 2005 (3) , pp.4-7.

[9] Wu Qihong. The inverter, programmable controller and touch screen integrated application technology [M]. 2 edition. Beijing: Mechanical Industry Press, (2010).

[10] Wang Agen. Electrically programmable principle and application [M]. 2 edition. Beijing: Tsinghua University Press, (2010).

[11] Longcheng Cui. Mitsubishi Motor small programmable controller application guide [M]. Beijing: Mechanical Industry Press, (2012).
