Breakdown Characteristics of Oil Impregnated Insulation Paper with Different Ageing Condition under the Composite Electric Field

Abstract:

There are many researches about the effect of oil/paper proportion, testing temperature, AC/DC ratio and other effects on the breakdown characteristics of oil-paper insulation under the composite electric field. However, the breakdown characteristics of oil-paper insulation under the composite electric field in the process of ageing are rarely reported. In this paper, the breakdown characteristics of the oil impregnated insulation paper with different ageing condition under the composite electric field were investigated. Results show that there is no necessary link between the breakdown characteristics and the ageing degree of oil-paper insulation. The breakdown voltage value decreased with the rise of the AC component under the composite electric field. The breakdown voltage with aged paper changed by new paper is slightly higher than that of the aged oil being changed by new oil.

• Periodical: Applied Mechanics and Materials (Volumes 513-517)
• Pages: 328-331
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.513-517.328
• Online since: February 2014
• Authors: Qian Wang*, Jian Hao, Tuan Liu, Jin Fu, Gao Lin Wu
• Keywords: Aging, Breakdown Characteristics, Composite Electric Field, Oil Impregnated Insulation Paper, Transformer

References

[1] C. D. Paraskevas, P. Vassiliou, C. T. Dervos: IEEE Transactions on Dielectrics and Electrical Insulation Vol. 13(2006), p.539.

[2] Lin Li, Feng Ji, Wenping Li, Youliang Sun, Gang Liu. Proceedings of the CSEE Vol. 30(2011), p.107.

[3] X. L. Wei, Y. H. Wang, et al. ICPADM, Vol. 1 (2009), p.20.

[4] C. Viswanatha, Sundara Rajan et al. ICDL Vol. 1(1999), p.219.

[5] Zhicheng Guan, Fuzeng Zhang, Guoli Wang, et al. ISH, Vol. 3(2005), p.1.

[6] K. Wen, Y. Zhou, J. Fu, et al. IEEE transactions on Power Delivery, Vo. 8(1993), p.223.
