New Method for Assessment Ageing Condition of Oil Impregnated Insulation Pressboard Based on Frequency Domain Spectroscopy

Abstract:

It is important to assess the condition of the cellulose insulation in transformer. However, taking paper samples from a transformer is both impractical and destructive. In this paper, a new method for assessment ageing condition of oil impregnated insulation pressboard based on frequency domain spectroscopy (FDS) was proposed. The FDS measurements were taken on oil impregnated insulation pressboards with five ageing levels at moisture content of 1.22%, 2.06%, 3.02% and 3.87%. The dielectric loss of all the samples were calculated by tanδ (f) interpolation and the ageing condition assessment database which contains data of five ageing levels and 1%-4% moisture content was built. It is found that the tanδ (f) interpolation is more sencentive to ageing and moisture. It could realize the ageing condition assessment by comparing the tanδ (f) interpolation curve with the curves in the database.The assessing result of the middle-low main insulation life of a 220kV transformer valided that it is effective and time saving to use the new method for ageing condition assessment.

• Periodical: Applied Mechanics and Materials (Volumes 513-517)
• Pages: 323-327
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.513-517.323
• Online since: February 2014
• Authors: Jian Hao*, Jin Fu, Pei Guo, Gao Lin Wu, Qian Wang, Yuan Shuai
• Keywords: Ageing Condition Assessment, Dielectric Loss, Frequency Domain Spectroscopy (FDS), Oil Impregnated Insulation Pressboard, Transformer

References

[1] C. D. Paraskevas, P. Vassiliou, C. T. Dervos: IEEE Transactions on Dielectrics and Electrical Insulation Vol. 13(2006), p.539.

[2] V. T. Morgan: IEEE Transactions on Dielectrics and Electrical Insulation Vol. 5(1998), p.125.

[3] D. Linhjell, L. E. Lundgaard, U. Gafvert: IEEE Transactions on Dielectrics and Electrical Insulation Vol. 14(2007), p.156.

DOI: 10.1109/tdei.2007.302884

[4] T. K. Saha, T. Y. Zheng: IEEE Trans. Power Del. Vol. 18(2003), p.128.

[5] CIGRE Task Force 15. 01. 09, Electra no. 202(2002).

[6] T. K. Saha, P. Purkait: IEEE Trans. Dielect. Electr. Insul. Vol. 11(2004), p.144.

[7] S. M. Gubanski, P. Boss, G. Csepes, et al: IEEE Electrical Insulation Magazine, Vol. 19(2003), p.12.

[8] J. H. Yew, T. K. Saha, A. Thomas: Proceedings of the IEEE Power Engineering Society General Meeting, Montreal, Canada 2006, p.1.

[9] D. Linhjell, U. Gäfvert, L. E. Lundgaard: Proc. CEIDP 2004, Boulder, Colorado, USA, p.262.

[10] U. Gäfvert, L. Adeen, M. Tapper, P. Ghasemi, B. Jonsson: IEEE 6th Int. Conf. on Properties Appl. Dielectr. Materials (ICPADM), Xian, China, Vol. 2(2000), p.825.

[11] T. Leibfried, A. J. Kachler, V. Der Houhanessian, A. Küchler and B. Breitenbauch: CIGRE Session, Paris, 2002, p.1.

[12] Ekanayake, Chandima, S. M. Gubanski: KIEE International Transactions on Electrophysics and Application, Vol. 4-c (2004), p.81.
