Real-Time Temperature On-Line Monitoring and Analysis System for Transformers

Abstract:

The safe operation of power transformers mainly depends on proper functioning of insulation, whose status is revealed by temperatures. Applying ZigBee wireless network, a real-time temperature on-line monitoring and analysis system is developed to view the operation status of underground distribution transformers and process fault diagnosis. Furthermore, using the top-oil and hot-spot temperature calculation method in IEEE Std C57.91-1995, the system can compute a prediction of those temperatures with current load ratio and ambient temperature. System will display early warnings if temperatures are much higher than expected ones, in which way insulation aging can be handled in advance. Insulation fault and big disasters will be prevented.

• Periodical: Applied Mechanics and Materials (Volume 521)
• Pages: 409-413
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.521.409
• Online since: February 2014
• Authors: Ya Bo Chen*, Yue Sun, Xu Ri Sun, Ge Hao Sheng, Xiu Chen Jiang
• Keywords: Hot-Spot Temperature, On-Line Monitoring, Top-Oil Temperature, Zigbee Wireless Network
