The Application and Development of Composite Material Detection Using Dry Coupled Acoustic Technology

Abstract:

This paper focus on the method of composite material detection, and five dry coupled acoustic technologies are introduced, which are dry pressure coupling method, acoustical impedance method, Local percussion method, air-coupled ultrasonic method and ultrasonic fixed spacing pitch-catch method. The principle, character and application of these five methods are discussed, and the development trend of dry coupled acoustic technology is previewed.

• Periodical: Applied Mechanics and Materials (Volume 526)
• Pages: 75-79
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.526.75
• Online since: February 2014
• Authors: Jian Li*, Chun An Ai, Xue Ren Wang, Xiao Jun Zhang
• Keywords: Acoustic, Composite, Detection, Dry Coupled

References

[1] Ruan Hongbin, Zheng Haiping. Study on positional ultrasonic defect inspection of nozzle composite divergence cone. [J]. Journal of Solid Rocket Technology, 2002, Vol25: 73-76.

[2] Zheng Haiping. Zhang Xinchun. Low frequency dry coupled ultrasonic technology in aerospace composite products Nondestructive Testing. 8th Annual Meeting of Shaanxi Province NDT, 2002: 17-20.

[3] Li Minxuan. Acoustic impedance method detection principle [M]. Beijing, Science Press, 1976: 26-57.

[4] Gou Haiou. A certain type of aircraft engine noise assay plates acoustic impedance inspection [J]. Nondestructive Testing, 2004, Vol28: 42-44.

[5] Cawley P, Adams R D. The mechanics of the coin-tap method of non-destructive testing[J]. Journal-of-SoundVibration, 1988, 122: 299-316.

DOI: 10.1016/s0022-460x(88)80356-0

[6] Peters J J, Barnard D J, Hudelson N A, et al. A prototype tap test imaging system: Initial field test-results[J]. AIP-Conference-Proceedings, 2000, 509(1): 2053-(2060).

DOI: 10.1063/1.1291323

[7] Chang Junjie, Lu Chao, etal. Non-contact Air-coupled ultrasonic detection principle and application [J]. Nondestructive Test, 2013, Vol31: 1-6.

[8] IMIELINSKA-K, CASTAINGS-M, WOJTYRA R, etal. Air-coupled ultrasonic C-scan technique in impact response testing of carbon fibre and hybrid: glass, carbon and Kevlar/epoxy composites [J]. Journal of Materials-Processing-Technology, 2004, 157-158: 513-522.

DOI: 10.1016/j.jmatprotec.2004.07.143

[9] Gomez T E. Acoustic impedance matching of piezoelectric transducers to the air[J]. IEEE Trans, Ultrasonic, Ferroelectrics, and-Frequency Control, 2004, 51(5): 624-633.

DOI: 10.1109/tuffc.2004.1308697

[10] Wang Z, Zhu W, Miao J, et al. Micromachined thick film piezoelectric transducer array[J]. Sensors and Actuators A Physical, 2006(130/131): 485-490.

DOI: 10.1016/j.sna.2005.10.054
