Comparison of Prognostic Algorithms Based on PF and EKF for Estimating Remaining Useful Life of Li-Ion Batteries

Abstract:

To estimate remaining useful life (RUL) of Li-ion batteries is a key factor for correct and safe battery management, particularly for the development of Battery Management System (BMS). A lumped parameter model which integrates the non-linear open-circuit voltage, current, temperature, cycle number, and remaining capacity and other dynamic characteristics is created based on the battery electrical characteristics is presented. A particle filter (PF) algorithm which syncretizes Li-ion battery electrochemical working process is proposed according to the sequence importance of re-sampling to predict its discharge end time in single cycle time and cycle life. Besides, for comparison, a extended Kalman filter (EKF) algorithm is also proposed to estimate the RUL based on the same statistics. Simulation results show that the PF algorithm according to lumped parameter model has a better precision in estimating RUL compared with the EKF algorithm.

• Periodical: Applied Mechanics and Materials (Volume 529)
• Pages: 616-620
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.529.616
• Online since: June 2014
• Authors: Jin Zhang*, An Tong Gao, Wen Bing Wang, Yu Sheng Han, Rong Gang Chen, Feng Zhang
• Keywords: EKF, End-of-Discharge, Li-Ion Battery, Lumped Parameter Model, PF

References

[1] Wakihara M, Yamamoto(Eds. ) O. Lithium Ion Batteries Fundamentals and Performance [M], Published by Kodansha Ltd, Tokyo(Japan), WILEY-VCH Verlag Gmbh, Weinheim(Federal Republic of Germany), (1998).

[2] Jin Zhang, Antong Gao, Ronggang Chen, et al. Discussion on the Li-on Battery Health Monitoring and Remaining –useful-life Prediction [C]. ICEEP 2013, Guilin, China. Advanced Materials Research, (2013).

DOI: 10.4028/www.scientific.net/amr.724-725.797

[3] Blanke, H., Bohlen, O., Buller, S., et al. Impedance measurements on lead-acid batteries for state-of-charge, state-of-health and cranking capability prognosis in electric and hybrid electric vehicles [J]. Journal of Power Sources. 2005, 144: 418-25.

DOI: 10.1016/j.jpowsour.2004.10.028

[4] Saha, B., Goebel, K. Li-ion battery capacity depletion in a particle filtering framework [C]. Annual Conference of the Prognostics and Health Management Society, San Diego, California, 27 September -1 October (2009).

[5] Kozlowski, J.D. Electrochemical cell prognostics using online impedance measurements and model-based data fusion techniques [J]. Aerospace Conference 2003, IEEE Proceedings, 2003, 7: 3257-3270.

DOI: 10.1109/aero.2003.1234169

[6] Orchard, M., Wu, B. G. Vachtsevanos. A Particle Filter Framework for Failure Prognosis [C] / Proceedings of WTC2005, Washington D.C., USA. World Tribology Congress III. (2005).

DOI: 10.1115/wtc2005-64005
