Research on Design and Nonlinear of Piezoelectric Pressure Sensor

Abstract:

Measuring circuit and equivalent circuit of piezoelectric sensor and its parameters of voltage, capacitance and charge are analyzed. The intensity, the sensitivity and natural frequency of pressure sensor are designed. The influence factors and compensation method of pressure sensor nonlinear such as effective area of diaphragm, pre-tightening force, and temperature are analyzed. Key words: Sensor; Piezoelectric wafer; Measure circuit; Equivalent circuit; Nonlinear

• Periodical: Applied Mechanics and Materials (Volumes 530-531)
• Pages: 50-53
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.530-531.50
• Online since: February 2014
• Authors: Guo Min Lin*, Fei Zhou, Chun Feng Li
• Keywords: Equivalent Circuit, Measure Circuit, Nonlinear, Piezoelectric Wafer, Sensor

References

[1] Guanglei ZHANG. Intelligent materials and structures system [M]. Beijing: Beijing University press, 2010 (In chinese).

[2] Haixia ZHU. Journal of chongqing institute of technology, 2009 (23): 50-52 (In chinese).

[3] Hongsheng HU. Journal of vibration test and diagnosis, 2004 (24) : 197-202 (In chinese).

[4] Yingchun LIU. Principle of sensor design and application [M]. Changsha: National defense technology university press, 2004 (In chinese).
