The Investigation of a Novel Large-Strain Sensor Based on a Dual Capacitive Structure

Abstract:

In this paper, a novel large-strain sensor based on a dual planar capacitive structure has been developed. It has the capacity of large-strain measurement up to 200,000 με (0.2 ε). The change in strain causes a measurable transformation in the capacitance of the sensor by relative shift of the overlap area between two capacitive plates, one fixed (i.e. fixed plate) and the other one movable (i.e. movable plate), and is thus converted into a voltage signal by a read-out circuit module. The dual capacitor structure was designed for increasing the initial capacitance and improving the resolution of sensors compared with a single capacitor structure. The experimental results showed that the sensor had a linearity of 2.29% full scale (FS), a hysteresis error of 1.146%FS, repeatability of 0.226%FS and a resolution of 0.5%FS, suggesting excellent performance of the sensor.

• Periodical: Applied Mechanics and Materials (Volumes 530-531)
• Pages: 66-70
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.530-531.66
• Online since: February 2014
• Authors: Cheng Li Duan, Ya Dong Jiang, Hui Ling Tai*, Li Jie Chen, Qi Dong Li, Ying Fei He
• Keywords: Dual Capacitive Structure, Large-Strain, Sensor

References

[1] Ying Huang, Genda Chen, Hai Xiao, Yinan Zhang and Zhi Zhou: Proc. of SPIE Vol. 7983 (2011), pp.798317-1.

[2] Xiaoyan Shen and YuChi Lin: Proc. of SPIE Vol. 8191(2011), p. 81911Z-1.

[3] Bradley Thompson and Hwan-Sik Yoon: Proc. of SPIE Vol. 7981 (2011), p. 79814H-1.

[4] Jie Huang, Tao Wei, Xinwei Lan, Jun Fan and Hai Xiao: Proc. of SPIE Vol. 8345 (2012), p. 83452Z-1.

[5] Haiting Di, Suping Sun, Jianqiang Yu and Renqiang Liu: Proc. of SPIE Vol. 7656 (2010), p. 76561C-1.

[6] Sheng Li, De sheng Jiang: Photonics and Optoelectronics 2009 (SOPO) Symposium (2009), pp.978-0.

[7] M. I. A. Mokti, I. A. Rahim and A. A. Manaf: IEEE RSM2011 Proc., (2011), p.329.

[8] R. P. Strittmatter, R. A. Beach, G. S. Picus and T. C. McGill: J. Appl. Phys. Vol. 94 (2003), p.5958.

[9] M. Suster, J. Guo and N. Chaimanonart: IEEE 2004 Custom Integrated Circuits Conference Vol. 31-3 (2004), p.693.

[10] S. Laflamme1, M. Kollosche, J. J. Connor and G. Kofod: Struct. Control Health Monit. Vol. 19 (2012), p.70.

[11] H. Hoyer, M. Knaapila, J. Kjelstrup-Hansen and G. Helgesen: J. Appl. Phys. Vol. 112 (2012), p.094324.

[12] Inpil Kang, Mark J Schulz1, JayHKim, Vesselin Shanov and Donglu Shi: Smart Mater. Struct. Vol. 15 (2006), p.737.

[13] Jianping Yu, Wen Wang, Xinxin Li, Zhu Zhu and Zichen Chen: Intelligent Computation Technology and Automation Second International Conference (2012), p.201.

[14] Chengli Duan, Yadong Jiang, Lijie Chen, Huiling Tai and Yingfei He: Integr. Ferroelectr. Vol. 147 (2013), p.123.
