Study on the Detection and Selection of Bearing Diameter Based on Machine Vision System

Abstract:

A new method and system for inspecting the bearing diameter is developed. The mechanical and movement control units, as well as its machine vision system, are designed. A precision measuring method based on machine vision system is developed to measure bearing diameter. Computer outputs the bearing edge contour and its three-dimensional coordinates after image processing software process the image of bearings which are collected by CCD camera. The controller controls the operation of motor by ball screws and drives the movement of individual parts which can crawls the gripper in the three-dimensional coordinates. Inductive gage is used to measure bearing diameter. Besides, a technology roadmap of image edge character detection is analyzed .Gaussian filter is used to noise reduction of the image and canny operator is used to edge detection. Template match is adapted to the automatic recognition of bearing characteristics. The paper may be helpful to those who work on the same subject in future.

• Periodical: Applied Mechanics and Materials (Volume 533)
• Pages: 298-302
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.533.298
• Online since: February 2014
• Authors: Fu Sheng Yu, Sheng Jiang Yin*, Teng Fei Li, Zhong Guo Sun, Wei Kang Shi
• Keywords: Automatic Detection, Bearing Diameter, Edge Character Detection, Machine Vision, Robot

References

[1] Chongjin Du, Danwen Sun. Pizza Sauce Spread Classification Using Color Vision and Support Vector Machines [J]. Journal of Food Engineering (S0260-8774), 2005, 66(2): 137–145.

DOI: 10.1016/j.jfoodeng.2004.03.011

[2] Basso, N Alexei, E Molto. Machine Vision System for Automatic Quality Grading of Fruit [J]. Bio systems engineering (S1537-5110), 2003, 85(4): 415–423.

DOI: 10.1016/s1537-5110(03)00088-6

[3] Liangjiang Liu, Yaonan Wang. Diameter of the Rolling bearing based on Machine Vision Inspection System [J]. System Simulation, 2007, 19(21): 4981-4984, 4989.

[4] Shoujun Ni, Wei Jiang. Position Error Analysis based on Bearing Diameter Online Measurement System [J] Bearing, 2005, (11): 33-36.

[5] BainingChen, Ming Zhao, Yajun Ren, Research on Non-contact Bearing Diameter Line Detection System [J]. Automation Instrumentation, 2009, (5): 54-55, 59.

[6] Jinxing Wang, Bin Xu, Naizhao Wang. Development of the Outer Diameter of the Rolling Bearings Intelligent Detector [J]. Journal of agricultural machinery, 2001, 32 (4): 122-123, 125.

[7] Liangyu Lei, Xiaojun Zhou, Mingqing Pan, Bearing Diameter Size Inspection System based on Machine Vision [J], Journal of agricultural machinery，2005, 36 (3) : 131-134.

[8] Mu Li, Jihong Yan, Ye Li, Adaptive Canny Edge Detection Technology [J] Harbin Engineering University, 2007, 28 (9): 1003 - 1007.
