Improved Efficiency in Organic Light Emitting Device Based on 4,4-bis(2,2-diphenylvinyl)-1,1-biphenyl as Hole Blocking Layer

Abstract:

An organic light emitting device (OLED) with multilayer structure is reported. The devices were made of ITO/ m-MTDATA (45 nm)/ NPB (10 nm) / DCJTB (0.05 nm)/DPVBi (x nm)/ Alq:QAD 0.5% 20nm /Alq (50-x nm)/LiF(1nm)/Al, by doping combine with non-doping method. The ultrathin layer was introduced for the yellow emitting layer by using 4- (dicyanomethylene)-2-tert-butyl-6 (1,1,7,7-tetramethyljulolidyl-9-enyl)-4H-pyran (DCJTB). The ultrathin layer offered an attraction in that it allowed the easy handling process and accurate thickness control, it enabled high device efficiency with simple architecture.The device shows the current efficiency of 2.79 cd/A at 12V, its maximum luminance is 17450 cd/m² at 14V, respectively.

• Periodical: Applied Mechanics and Materials (Volumes 536-537)
• Pages: 1426-1430
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.536-537.1426
• Online since: April 2014
• Authors: Hui Shan Yang*, Li Shuang Wu, Zhi Yue Huang
• Keywords: Efficiency, Luminance, Organic Light-Emitting Diode (OLED)

References

[1] C. W. Tang and S. A. VanSlyke: Appl. Phys. Lett. Vol. 51(1987), p.913.

[2] Kido J, Kimura M and Nagai K: Science. Vol. 267(1995), p.1332.

[3] D'Andrade B W, Brooks J, Adamovich V, Thompson M E and Forrest S R: Adv. Mater. Vol. 14(2002), p.1032.

[43] D'Andrade B W, Thompson M E and Forrest S R: Adv. Mater. Vol. 14(2002), p.147.

[5] D'Andrade BW, Holmes R J and Forrest S R: Adv. Mater. Vol. 16(2004), p.624.

[6] Lei G T, Wang L D and Qiu Y: Appl. Phys. Lett. Vol. 85(2004), p.5403.

[7] Chuen C H, Tao Y T, Wu F I and Shu C F: Appl. Phys. Lett. Vol. 85(2004), p.4609.

[8] Liu T H, Wu Y S, Lee M T, Chen H H, Liao C H and Chen C H: Appl. Phys. Lett. Vol. 85(2004), p.4304.

[9] Ko C W and Tao Y T: Appl. Phys. Lett. Vol. 79(2004), p.4234.

[10] Tsuji T, Naka S, Okada H and Onnagawa H: Appl. Phys. Lett. Vol. 81(2002), p.3329.

[11] Yook K S, Jeon S O, Joo C W, Lee J Y: J. Lumin. Vol. 130(2010), p, 1211.

[12] Divayana Y, Liu S M, Kyaw A K K, Sun X W: Org Electron. Vol. 12(2011), p.1.

[13] Liu S M, Li B, Zhang L M, Song H, Jiang H: Appl Phys Lett. Vol. 97(2010), p.083304.

[14] Zhao J, Yu J S, Liu S Q, Jiang Y D: J. Lumin. Vol. 132(2012), p, (1994).

[15] Zhao Y B, Chen J S, Ma D G: Appl Phys Lett. Vol. 99(2011), p.163303.

[16] Li H Y, Zhang C H, Li D C, Duan Y: J. Lumin. 2007Vol. 122–123(2007), p.626.

[17] Linde S, Carella A, Shikler R: Macromolecules. Vol. 45(2012), p.1476.
