Deep Drawing and Bulging Processes of Hard-Deformed Light Alloy Sheet with Resistance Heating

Abstract:

For enhance the heating efficiency and the formability of the magnesium alloy and aluminium matrix composite sheets, pulse current is adopted to the gas bulging and stamping processes. During the bulging process of magnesium alloy sheet, the effects of dynamic pulse current on the formed sheet combine both thermoelectricity and electro-plasticity. The effect and the applicability of the pulse current heating have been evaluated. The deformation properties, microstructure characteristics, and dislocation movement of the AZ31 alloy sheet during bulging process by the resistance heating are investigated. And the resistance heating has been adopted to improve the formability of SiC_p/2024Al composites in stamping process. The pulse current density achieved 21.7A/mm² and temperature of SiC_p/2024Al composite correspondingly reached to around 400°C in the 50s. The results showed that stainless steel inserts between sheet and copper electrodes successfully prevented the heat dissipation and promote temperature uniformity over the sheet during electrifying. In addition, workpiece formed by the pulse current deep drawing shows better shape retention, surface quality and high geometry dimensional accuracy.

• Periodical: Applied Mechanics and Materials (Volumes 541-542)
• Pages: 268-272
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.541-542.268
• Online since: March 2014
• Authors: Zhan Jiao Gao, Kai Feng Zhang, Bo Wang, Chao Li
• Keywords: AZ31 Magnesium Alloy, Bulging, Deep Drawing, Resistance Heating, SiC_p/2024Al Composites

References

[1] M.T. Perez-Prado, O.A. Ruano. Texture Evolution during Annealing of Magnesium AZ31 Alloy. Scripta Materialia. (2002) 46: 149-155.

DOI: 10.1016/s1359-6462(01)01212-x

[2] B.L. Mordike, T. Ebert. Magnesium Properties, Applications, Potential. Materials Science and Engineering. (2001) A302: 37-45.

[3] A.A. Luo. Recent Magnesium Alloy Development for Automotive Powertrain Applications. Magnesium Alloys (2003) 419(4): 57-6.

DOI: 10.4028/www.scientific.net/msf.419-422.57

[4] Y. Sahin. Preparation and some properties of SiC particle reinforced aluminium alloy composites. Materials and Design 24 (2003) 671–679.

DOI: 10.1016/s0261-3069(03)00156-0

[5] K. Moria, S. Makia and Y. Tanaka. Warm and hot stamping of ultra high tensile strength steel sheets using resistance heating. CIRP Annals-Manufacturing Technology. (2005) 54/1: 209-212.

DOI: 10.1016/s0007-8506(07)60085-7

[6] B. Mohan, A. Rajadurai, K.G. Satyanarayana. Electric discharge machining of Al–SiC metal matrix composites using rotary tube electrode. Journal of Materials Processing Technology 153–154 (2004) 978–985.

DOI: 10.1016/j.jmatprotec.2004.04.347

[7] D.J. Lloyd. Particle reinforced aluminium and Mg matrix composites. Int. Mater Rev (1994) 39: 1–24.

[8] H. Takuda, T. Enami, K. Kubota. The Formability of a Thin Sheet of Mg-8. 5Li-1Zn Alloy. J. Mater. Proc. Tech. (2000) 101: 281-286.

DOI: 10.1016/s0924-0136(00)00484-2

[9] J. Yanagimoto, R. Izumi. Continuous electric resistance heating—Hot forming system for high-alloy metals with poor workability. Journal of materials processing technology. (2009) 209. 3060-3068.

DOI: 10.1016/j.jmatprotec.2008.07.010

[10] K. Mori, S. Maki, Y. Tanaka. Warm and hot stamping of ultra high tensile strength steel sheets using resistance heating. Ann. CIRP. (2005) 54 (1) 209-212.

DOI: 10.1016/s0007-8506(07)60085-7

[11] S. Tomida, T. Nagae, K. Nakata. Pulsed electric-current press bonding of aluminum alloy to stainless steel. Novel Materials Processing by Advanced Electromagnetic Energy Sources, 19-22(2004)313-316.

DOI: 10.1016/b978-008044504-5/50065-9
