The Study of Oscillating Lightning Impulse Voltage Generator for a 110kV GIS Field Test

Abstract:

The impulse voltage test for power equipment such as GIS is not performed in the field for the impulse voltage generator huge and difficult to operate. The oscillating impulse voltage that proposed by IEC60060-3 is a higher generation efficiency impulse waveform and suitable used in field. The oscillating lightning impulse voltage generator for a 110kV GIS field test is studied in this paper. The generator structure is described and the waveform parameter computer formula is derivate. Simulation and test shown the generator can produce impulse voltage that meet IEC60060-3 requirement.

• Periodical: Applied Mechanics and Materials (Volumes 543-547)
• Pages: 625-628
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.543-547.625
• Online since: March 2014
• Authors: Jing Gang Yang*, Yong Yong Jia, Zhi Cheng Zhou, Jun Hao Li
• Keywords: Generator, GIS, IEC60060-3, Impulse Voltage

References

[1] Thione, L., Spinelli, A., bossi, A., Sesto, E., Sigaudi, G., Babare. IEEE Transactions on Power apparatus and systems, 1980, 2, 779-789.

DOI: 10.1109/tpas.1980.319673

[2] IEC 60060-3 High Voltage Test Techniques Part 3: Definitions and Requirements for On-site Tests[S], (2005).

[3] Renyu Zhang, Changyu Chen and changchang wang. High voltage technology. Beijing : Tsinghua University Press, (2003).
