Design for Remote Monitoring System of Digital Radio and Television Transmitter

Abstract:

In order to achieve the remote monitoring of transmitter running status, a transmitter architecture of remote monitoring system based on a three-layer C/S architecture is proposed, and the overall design of the system is presented. Compared with the traditional two layers structure, the function of the client data processing is separated for implementing alone, which is treated as a middle layer called business logic layer. LabVIEW is used for the software development of the system. Communication of the local monitoring system is achieved by the Ethernet network based on TCP/IP protocol. SQL Server database is adopted to store and manage the run data and log data. The result shows that the system has good flexibility and extensibility, it also has higher application value and popularization value.

• Periodical: Applied Mechanics and Materials (Volumes 543-547)
• Pages: 908-911
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.543-547.908
• Online since: March 2014
• Authors: Hong She Dang*, Gang Wang, Ying Zhang
• Keywords: LabVIEW, Remote Monitoring, SQL Server Database, Three-Layer c/s Architecture, Transmitter

References

[1] Shihong Dang, Hongshe Dang. Design of Ethernet Based on Embedded Remote Monitoring System in Radio Transmitters [J]. Video Engineering. 2009, 8(33): 93-98.

[2] Jia Haitao, Can Li. A remote data acquisition system based on SMS [C]. 2004 IEEE International Conference on Systems. 2006, 7: 6155-6159.

DOI: 10.1109/icsmc.2004.1401365

[3] Chunlai Zhou. Monitoring System of TV Transmitter Based on Browser/Server mode[C]. International Conference on Information Acquisition. 2007: 95-100.

DOI: 10.1109/icia.2007.4295705

[4] XU Shu-ping, SU Xiao-hui. Transmitter Remote Control System Based on the Embedded Web [J]. Control Technology. 2011, 5(30): 82-84.

[5] XU Yan-chao. Multi-channel radio and television transmitter automatic monitoring system [J]. Manufacturing Automation. 2009, 12(31): 20-23.
