A Rotary Spiral Array Applied in Near-Field Acoustical Holography

Abstract:

This paper presents a new method to apply a spiral array in near-field acoustical holography (NAH). Usually, a NAH array needs much more microphones than a beamforming array does. Superior to a normal regular planar grid array or linear scanning array, this spiral array rotates to get more measuring data. Without a static referring microphone, a numerical method was designed to estimate the phase information measured at different time. Numerical simulations and a series experiment showed that this method is adequate for the sound below 450Hz. It is especially useful for using a random planar array at NAH mode, while the beamforming mode can only cover the higher frequency band.

• Periodical: Applied Mechanics and Materials (Volume 551)
• Pages: 202-209
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.551.202
• Online since: May 2014
• Authors: Lin Song Chen*, Yue Yun Cao, Wen Yong Guo
• Keywords: Acoustic Noise Localization, Beam-Forming, Equivalent Source Model, Spiral Array

References

[1] J.Q. Li. Research of a Fault Feature Extraction Technique Based on Acoustical Holography. (Ph.D., Shanghai Jiao Tong University, China 2008), pp.15-18.

[2] S.F. Wu. Methods for reconstructing acoustic quantities based on acoustic pressure measurements, J. Acoust. Soc. Am, vol. 124 (2008) No. 5, pp.2680-2697.

DOI: 10.1121/1.2977731

[3] Y. R. Zheng, R. A. Goubran, and M. El-Tanany, Robust near-field adaptive beamforming with distance discrimination, IEEE Trans. Speech Audio Process, vol. 12(2004) No. 5, pp.478-488.

DOI: 10.1109/tsa.2004.832982

[4] Maynard J D, Williams E G, Lee Y. Near-field acoustic holography: I. Theory of generalized holography and the development of NAH. J. A. S. A, vol. 78 (1985) No. 4, pp.1395-1413.

DOI: 10.1121/1.392911

[5] Mingsian R. Bai, Jeong-Guon Ih, Jacob Benesty: Acoustica Array Systems (John Wiley & Sons Singapore Pte. Ltd, Singapore 2013), p.149, 207.

[6] B. Jin, Y. Zheng, A meshless method for some inverse problems associated with Helmholtz equation, Computer Methods in Applied Mechanics and Engineering, 195(2006), pp.2270-2288.

DOI: 10.1016/j.cma.2005.05.013

[7] F. Yu, Wave Superposition Approach based Acoustic Holography and Acoustic Sensitivity Analysis, (Ph.D., Hefei University, China 2005), P. 101-116.

[8] Andreas Kirsch, An Introduction to the Mathematical Theory of Inverse Problems, Springer Science+Business Media, USA 2011), pp.63-80.

[9] D. Calvetti, S. Morigi, L. Reichel, F. Sgallari, Tikhonov regularization and the L-curve for large discrete ill-posed problems, Journal of Computational and Applied Mathematics 123 (2000), pp.423-446.

DOI: 10.1016/s0377-0427(00)00414-3

[10] P. C. Hansen, Regularization Tools A Matlab Package for Analysis and Solution of Discrete Ill-Posed Problems, (Informatics and Mathematical Modelling Building 321, Technical University of Denmark 2008 ), pp.25-29.

[11] S.F. Wu, L.K. Natarajan, Panel acoustic contribution analysis. J. Acoust. Soc. Am. Vol. 133 (2013) No. 2, pp.799-809.
