Structural Optimization of Three Translational Parallel Sorting Robot

Abstract:

The kinematics model of the robot was established, and its structural parameters were studied. Based on coordinate transformation, the inverse solution of the robot was obtained. Its workspace was solved by MATLAB program. Three-dimensional diagram and projection drawing on XY plane of workspace were obtained. In addition, the sorting range various with the different value of Z was studied and obtained. Finally, on the premise of meeting working range of the robot, using the minimum mass of the moving parts as optimization objective, the structural parameters of the sorting robot were optimized using the search method. Simulation results show that the optimized robot can achieve the minimum weight of moving parts and meet the preset sorting range. It is also ensured the sorting flexibility.

• Periodical: Applied Mechanics and Materials (Volume 552)
• Pages: 179-182
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.552.179
• Online since: June 2014
• Authors: Jun Xie*, Hui Deng, Qi Zhi Yang, Yue Liu
• Keywords: Location Analysis, Parallel Robot, Structural Optimization, Workspace Calculation

References

[1] Minglei Li. Analysis and Optimization of Parallel Robot Mechanism[D]. Taiyuan: Taiyuan University of Science & Technology, 2010. In Chinese.

[2] Jun Xie, Yue Liu and Chaopeng Xiao. [J]. Chinese Journal of Engineering Design, 2013, 20(6): 501-506. In Chinese.

[3] Chunlin Zhang, Yueqing Yu. Theory of Higher Mechanisms[M]. Beijing: Beijing Institute of Technology Press, 2006: 13~19. In Chinese.

[4] Qiushi Technology. MATLAB 7. 0 From the introduction to the master[M]. Beijing: Posts & Telecom Press, 2006. In Chinese.

[5] Jingmin Sun, Yingchun Liang. Optimal design of machine[M]. Beijing: China Machine Press, 2011. In Chinese.

[6] S. Ganesh, A.B. Koteswara Rao and Sanjay Darvekar. [J]. Journal of Mechanical Science and Technology, 2013, 27(12): 3797-3804.
