Flow Characteristic and Optimal Design of Rectangularly Tapered Header Based on CFD

Abstract:

In order to study reasonable structure of rectangular tapered header, the methed of computatation fluid dynamic was used to research pulp distribution characteristic of the rectangularly tapered pulp distributor and to optimize its structure. The results show that velocity distribution and pressure distribution in the tapered header were not uniform and the mass flow rate out of branch pipes was obviously accrescent from inlet of header to outlet of header. There was remarkable deviation comparison to expected value of mass flow rate. The real backwall shape of the rectangularly tapered head was a complicated curve that was obviously different to the simplified header at area of the inlet and the outlet. The pressure distribution in the optimally designed header was more uniform and the pressure curve at the location corresponding to branch pipes was nearly a horizontal line. The mass flow rate distribution out of the branch pipes was more uniform else and was close to the expected value curve. The deviation of the mass flow rate in every branch pipe was less than 1%.

• Periodical: Applied Mechanics and Materials (Volume 552)
• Pages: 20-23
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.552.20
• Online since: June 2014
• Authors: Xiao Hui Ji*, Wei Liu
• Keywords: CFD, Flow Characteristic, Header, Optimal Design

References

[1] W. Liu, K.F. Chen, J. Li. 4th ISETPP, Guangzhou, China, 2010: 1260-1263.

[2] K.F. Chen. Fluid dynamic at wet section of the paper machine. Beijing: China Light Industry Press. 1984(In Chinese).

[3] K.F. Chen. Pulp and papermaking machinery and equipment. Beijing: China Light Industry Press (Second edition). 2008(In Chinese).

[4] J.A. Liu, K.F. Chen. Transactions of China Pulp and Paper. 2005, 20(1): 161-163(In Chinese).

[5] D. W. Wang. Optimizing Design of Headbox Tapered Distributor based on Matlab. China Pulp & Paper. 2006, 25(9): 23-26(In Chinese).

[6] D. Traft. Tian Jin Pulp and Paper, 1984(4): 36-45(In Chinese).

[7] J. Hämäläinen, R. A. E. Mäkinen and P. Tarvainen. Int. J. Numer. Meth. Fluids 2000, 34: 685-700.

[8] K. Pougatch,M. Salcudean. Tappi Journal, 2005, 4(10): 3-8.

[9] W. Liu. China Paper & Paper Industry, 2013, 34(8): 30-33(In Chinese).
