Flow and Separation Performance of Supersonic Gas Separator

Abstract:

A study on the flow and separation performance of supersonic gas separator is carried out through numerical simulation and experimentation. The effect of area ratio on the separation performance under low pressure ratio has been researched. The simulation results indicate that with an increase of the area ratio AR, the intensity of the shockwave increases and the location approaches the throat; Shockwaves are absent in the diverging section of the nozzle when area ratio is 1.063 and the pressure ratio is within 1.25-1.75, which reaches the highest separation performance. The calculated and experimental results also show that the separation performance is the highest and can reach 40.82% when pressure ratio is 1.75. The calculated values are in agreement with the experimental results.

• Periodical: Applied Mechanics and Materials (Volume 552)
• Pages: 3-7
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.552.3
• Online since: June 2014
• Authors: Jian Hua Zhao*, Pei Qi Liu, Da Peng Hu
• Keywords: Area Ratio, Laval Nozzle, Separation Performance, Shock Wave, Supersonic Separator

References

[1] J.M. Brouwer and H.D. Epso, in: Twister supersonic gas conditioning for unmanned platforms  and subsea gas processing, UK (2003).

DOI: 10.2118/83977-ms

[2] S.P. Zhang, W.G. Sheng and Z.G. Yu: Journal of Engineering Thermophysics, Vol. 29(2008) p.1875(in Chinese).

[3] F. Okimoto, S. L, Shu, J.M. Fan: Foreign Oil Field Engineering, Vol. 19(2003) p.32(in Chinese).

[4] D.P. Hu, Y.Q. Dai and J.P. Zou, China. Patent ZL200810011258. 6(2010).

[5] M. Yu and Y.H. Liu: Science Technology and Engineering, Vol. 11(2011) p.7979(in Chinese).
