Research on Simulation of Virtual NC Lathe Machining Process

Abstract:

Virtual NC lathe machining simulation system is carried out with Visual C++ and Open Inventor software. The system possesses visible UI, interactive inputting workpiece and machining parameters, the integration of geometric simulation and physical simulation, all the simulation functions including real-time display machining process, tool moving, workpiece geometry shape change, the generation and movement of iron simulation, workpiece pressure shape change could be realized. Tool temperature analysis and stress & strain analysis are simulated in the cutting process by FEM. The simulation results show the high efficiency of the simulation algorithm, reasonable simulation results, lifelike. The practice and training could be replaced by the virtual one. The system is applied to verification of NC code, quality evaluation of machine operators, operators, CNC programming staff training and other functions.

• Periodical: Applied Mechanics and Materials (Volume 552)
• Pages: 381-386
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.552.381
• Online since: June 2014
• Authors: Li Bo Zhou*, Fu Lin Xu, Zhi Xiong Shen
• Keywords: Cutting Simulation, Geometric Simulation, Physical Simulation, Strain, Stress, Temperature

References

[1] WANG Qi-yi, GE Yan-jun, SHI Zhi-hui, LU Bi-hong, The Simulation Technology for NC Turning Based on the Virtual Machining Environment, Mechanical Design & Manufacturing Engineering, Vol. 30, 1, 2001: 39-40, In Chinese.

[2] ZHAO Bin, SHI Zhihui etc, Study about real-time simulation of chip generating, curling and breaking, Modular Machine Tool & Automatic Manufacturing Technique, 2000. 8: 12-15.

[3] Huixia Liu, Xiao Wang, Virtual NC Laser Cutting Machine Tool and Cutting Process Simulation, Proceedings of SPIE Fourth International Conference on Virtual Reality and Its Applications in Industry, 2003. 10.

DOI: 10.1117/12.561170

[4] Hai-long CUI; Jie LIN; Dan-chen ZHOU; Ao BAI; Research on the Method of Cutting Force Simulation in CNC Machining Process, Proceedings of 2013 IEEE International Conference on Computer Science and Automation Engineering, Vol. 01, 2013. 11.

[5] ZHANG Yu-xia, WANG Pei-jun, HU Zhi-yuan, NIE Liang-bing, PAN Xuan, Study of Virtual NC Simulation of Milling Hole Based on OpenGL and VC + +, Machine Building & Automation, Jun 2013, 41( 2) : 97-99, In Chinese.

[6] I. O. Aver'yanova; R. K. Prodan, Using the Pro/ENGINEER system for geometric simulation in numerically controlled electroerosional broaching machines, Russian engineering research, 2010, Vol. 30, No. 6: 633-635.

DOI: 10.3103/s1068798x10060237
