Design of Ultrasonic Cutting Bench for Automatic Tape Laying Machine

Abstract:

Automatic tape laying is a widely-used fabricating process for fiber-reinforced composite materials in aerospace and aviation industry. To fulfill the tape laying process, it is necessary to cut the prepreg tape into designated shape accurately and promptly. In this paper, a scheme of ultrasonic cutting bench is put forward to investigate the parameters of ultrasonic cutting process. The functional requirements are analyzed and the key components of ultrasonic cutting bench, such as transverse feed mechanism of cutter, revolving gear of cutter, and mechanism for precision positioning of cutting depth, are presented in detail, which lays a solid foundation for future experimental research.

• Periodical: Applied Mechanics and Materials (Volume 552)
• Pages: 80-85
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.552.80
• Online since: June 2014
• Authors: Zhen Yu Han*, Fa Cun Hu, Hua Lu, Hong Ya Fu
• Keywords: Automatic Tape Laying, Ultrasonic Cutter, Ultrasonic Cutting

References

[1] Liwei Wen, Biao Yan, Jun Xiao, and Jianbao Zhang: Aeronautical Manufacturing Technology Vol. 17(2010), p: 49-52.

[2] Q L ZHOU, Z Y TAO, J SHA: submitted to China Mechanical Engineering (2013, 12).

[3] Jingquan Liu, Jiuchun Yan, Shiqin Yang, Qin Wang, and Tao Xu: Panasonic Vol. 8(2001).

[4] Grimshaw M N, Grant C G, Diaz J M L. Advanced technology tape laying for affordable manufacturing of large composite structures. In International SAMPE Symposium and Exhibition. SAMPE; (1999).

[5] Information on http: /www. cs. odu. edu/~mln/ltrs-pdfs/NASA-99-44sampe-abh. pdf.
