Research on Simulation of Marine Refrigeration System Based on Simulink

Abstract:

A simulation based on simulink was set up to investigate the performance of marine refrigeration system. For the simulator focused on the operation and management, so the steady state simulation algorithm is to be used to build simulator of the whole system, it gives consideration to both efficiency and precision of simulation calculation, real-time of operation and management is increased. Compressor thermal model is simple, most of that use steady-state model with no iterative computation. Due to the need of teaching and simulation operation, we use lumped parameter method and partition method to establish mathematical model of Condenser, evaporator, expansion valve, evaporator pressure regulator, cold storage and other parts. True-time operation and the appraisal function has developed. The simulation result accorded well with the experiment result. This model precision is high and timely. It was acceptable used in the ships refrigeration system's operation.

• Periodical: Applied Mechanics and Materials (Volume 552)
• Pages: 61-65
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.552.61
• Online since: June 2014
• Authors: Yun Xin Liu*
• Keywords: Appraisal, Dynamic Simulation, Model, Refrigeration System

References

[1] Baolong Wang, Wenxing Shi, Xianting Li. Mathematical modeling of scroll refrigeration compressors [J]. J Tsinghua Univ (Sci & Tech), 2005, 45(6): 726—729（In Chinese）.

[2] Wuchao Wang, Jingquan Zhao. Dynamic simulation of condenser [J]. Journal of Engineering Thermophysics, 2005, 26(4): 631—634（In Chinese）.

[3] Binglu Ruan, Guangbin Liu, Yuanyang Zhao, Liansheng Li. Numerical simulation of flow inside falling film evaporator with horizontal tubes refrigeration system [J]. Journal of Xi'An Jiaotong University, 2008, 42(3): 318—322（In Chinese）.

[4] Zhigang Wu, Guoliang Ding. Fast calculation for subcooled refrigerant thermodynamic properties [J]. Journal of Shanghai Jiaotong University, 2006, 40(8): 1385—1388（In Chinese）.

[5] Guoliang Ding, Chunlu Zhang. Model-based intelligent simulation of refrigeration system [J]. Journal of Engineering Thermophysics，2001, 22(5): 552—554（In Chinese）.

[6] Ruiqi zhu, Jiaze Xie, Yezheng Wu. Model of refrigeration system for optimizing control [J]. Journal of Xi'An Jiaotong University, 2002, 36(5): 461—464（In Chinese）.

[7] Chunlu Zhang, Guoliang Ding. A generalized algorithm for steady-state simulation of refrigeration systems [J]. Journal of Shanghai Jiaotong University, 2002, 36(11): 1667—1670（In Chinese）.

[8] Yongming Zhou, Zhijiu Chen. Modeling and simulation of a refrigeration system for control purpose [J]. Journal of Shanghai Jiaotong University, 1999, 33(3): 255—258（In Chinese）.
