Aerodynamic Characteristics of a Deformable Membrane Aerofoil

Abstract:

In the paper, numerical and experimental study of low Reynolds number airflow around the deformable membrane airfoil (DMA) is presented. Simulations of a fluid-structure interaction between the fluid and the DMA were performed. In the experiment, the DMA model was made from a thin PVC sheet, which was wrapped around the steel rod at the leading and trailing edge. Measurements were performed in a wind tunnel at a chord Reynolds number of 85.7·10³, over the angle of attack range from 0° to 15° and DMA shortening ratio from 0.025 to 0.150. Simulations were in an agreement with the experiment, since the average relative difference of coefficient of lift was smaller than 7.3%. For the same value of Reynolds number, DMA shows improved lift coefficient C_y= 2.18, compared to standard rigid airfoils.

• Periodical: Applied Mechanics and Materials (Volume 553)
• Pages: 255-260
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.553.255
• Online since: May 2014
• Authors: Viktor Šajn*, Igor Petrović, Franc Kosel
• Keywords: Deformable Membrane Airfoil, High Lift Aircraft Wing, Interaction Solid-Fluid, Wind Tunnel

References

[1] B. Thwaites, The aerodynamic theory of sails I. two-dimensional sails, Proceedings of the Royal Society, Series A 261 (1961) 402–422.

DOI: 10.1098/rspa.1961.0086

[2] J. Nielsen, Theory of flexible aerodynamic surfaces, Transactions of the ASME - Journal of Applied Mechanics (1963) 435–442.

[3] B. Newman, H. Low, Two-dimensional impervious sails: experimental results compared with theory Journal of Fluid Mechanics 144 (1984) 445–462.

DOI: 10.1017/s0022112084001683

[4] S. Cyr, B. Newman, Flow past two-dimensional membrane aerofoils with rear separation, Journal of Wind Engineering and Industrial Aerodynamics 63(1–3) (1996) 1–16.

DOI: 10.1016/s0167-6105(96)00065-7

[5] V. Šajn V, F. Kosel, B. Štok, Numerical simulation of wind flow around an elastic inflated membrane, International Journal for Engineering Modelling 16(3–4) (2003) 83–88.

[6] W. Shyy, F. Klevebring, M. Nilsson, J. Sloan, B. Carroll, C. Fuentes, Rigid and flexible low Reynolds number airfoils, Journal of Aircraft 36(3) (1999) 523–529.

DOI: 10.2514/2.2487

[7] R. Smith, W. Shyy, Computation of aerodynamic coefficients for a flexible membrane airfoil in turbulent flow: A comparison with classical theory, Physics of Fluids 8(12) (1996) 3346–3353.

DOI: 10.1063/1.869122

[8] B. Stanford, P. Ifju, R. Albertani, W Shyy, Fixed membrane wings for micro air vehicles: Experimental characterization, numerical modeling and tailoring, Progress in Aerospace Sciences 44(4) (2008) 258–294.

DOI: 10.1016/j.paerosci.2008.03.001

[9] E. R. Van Driest, On turbulent flow near a wall, Journal of the Aeronautical Sciences, 23(11) (1956) 1007-1011.

DOI: 10.2514/8.3713
