PID Control System for a Distributed Parameter Process

Abstract:

This paper presents the numerical simulation of a control system, with PID algorithm, for a process modeled through a partial differential equation of second order (PDE II.2), with respect to time (t) and to a spatial variable (p). Because these types of control systems are less usual, this paper develops a case study, with a program run on the computer. The details of using the PID control are pointed out, for an example of a system which contains a process with PDE II.2 structure.

• Periodical: Applied Mechanics and Materials (Volume 555)
• Pages: 222-231
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.555.222
• Online since: June 2014
• Authors: Mihaela Ligia Ungureşan, Vlad Mureşan*
• Keywords: Control System with PID Algorithm, Matrix of Partial Derivatives of the State Vector (Mpdx), Partial Differential Equation, State Vector

References

[1] L. Debnath: Nonlinear Partial Differential Equations, for Scientists and Engineers, Fourth Edition, edited by Birkhäuser Publishing, Boston, Basel, Berlin, 2007, pg. 771.

[2] H. -X. Li and C. Qi: Spatio-Temporal Modeling of Nonlinear Distributed Parameter Systems: A Time/Space Separation Based Approach, 1st Edition, edited by Springer Publishing, 2011, pg. 194.

[3] M. Krstic: Systematization of approaches to adaptive boundary control of PDEs, Int. Journal of Robust and Nonlinear Control, vol. 16 (2006), pp.801-818.

DOI: 10.1002/rnc.1098

[4] R.F. Curtain and K.A. Morris: Transfer Functions of Distributed Parameter Systems, Automatica, 45, 5 (2009), pp.1101-1116.

DOI: 10.1016/j.automatica.2009.01.008

[5] P. Frihauf and M. Krstic: Leader-enabled deployment into planar curves: A PDE-based approach, IEEE Transactions on Automatic Control, vol. 56 (2011), pp.1791-1806.

DOI: 10.1109/tac.2010.2092210

[6] T. Coloşi, M. Abrudean and M. Ungureşan: The Taylor Series – Local Iterative Linearization Method for Numerical Modeling and Simulation of Linear Processes, IEEE Proceedings, AQTR 2008 (THETA 16), May 22-24, 2008, Cluj-Napoca, Romania, p.221.

DOI: 10.1109/aqtr.2008.4588825

[7] M. Abrudean, T. Coloşi and M. Ungureşan: Truncation Errors of the Operator Matrix Mdpx, for Numerical Modelling and Simulation of the Distributed Parameter Processes, 16th Int. Conf. on Control Systems and Computer Science, CSCS -16, edited by Printech Bucharest Publishing, May 22 – 26, 2007, pp.66-74.

[8] T. Coloşi, M. Abrudean, M. -L. Ungureşan and V. Mureşan: Numerical Simulation Method for Distributed Parameters Processes, Springer Publishing Press, 2013, pg. 343.

DOI: 10.3182/20130522-3-ro-4035.00004

[9] I. -V. Sita: Building Control, Monitoring, Safety and Security using Collaborative Systems, 4th Int. Conf. on Intelligent Networking and Collaborative Systems, Bucharest, Romania, 2012, pp.662-667.

DOI: 10.1109/incos.2012.107

[10] C. Ile: Analyze the process capability, Applied Mechanics and Materials, vol. 436, 2013, pp.311-317.

[11] F. Golnaraghi and B. C. Kuo: Automatic Control Systems, edited by Wiley Publishing, 9th edition 2009, pg. 800.

[12] J. Love: Process Automation Handbook, 1 edition, edited by Springer Publishing, 2007, pg. 1200.
