Finite Element Static Analysis of YP2080 Automatic Hydraulic Press

Abstract:

The paper took 2080 tons automatic hydraulic tile press as the research object, completed the finite element static analysis of its beam and base. Established their three-dimensional models with CAD software Pro/ENGINEER, and then analyzed the stress and transfiguration with CAE software ANSYS. Studied the distribution of the stress and strain, and found their maximum and location. The result can provide some good reference for design and optimization.

• Periodical: Applied Mechanics and Materials (Volumes 556-562)
• Pages: 1046-1049
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.556-562.1046
• Online since: May 2014
• Authors: Dong Qing Lv*
• Keywords: Beam Base, Ceramic Tile, Finite Element, Hydraulic Press, Static Analysis

References

[1] Zhicheng Huang. The finite element analysis on the upper beam of automatic hydraulic press. Mechanical design and manufacturing, (2007).

[2] Baiqing Zhang, etc. Automatic hydraulic press. Nan Chang：Jiangxi Science and Technology Press, (2002).

[3] ANSYS. INC. Basic Analysis Procedures Guide. Release5. 7.

[4] ANSYS. INC. Modeling and Meshing Guide. Release5. 7.

[5] Zhicheng Huang, Nanxing Wu, Xingguo Wang. Contact Analysis on The Whole Frame of 32. 8MN PRESS. TELKOMNIKA. 2013; 11(7): 3863 ~ 3873.

[6] Zhicheng Huang, Nanxing Wu, Xingguo Wang. Contact Analysis on Thread Connections of 32. 8MN PRESS Columns. TELKOMNIKA. 2013; 11(7): 3964 ~ 3972.
