Static Analysis and Modal Analysis of Heavy-Load Manipulator Based on ANSYS

Abstract:

The heavy-load manipulator arm, an important part of the remote handling maintenance system of the large-scale multi-purpose deployer, plays a key role of the entire system. Its modeling and assembly was finished by Pro/E. Then use the ANSYS Workbench, finite element analysis software, to complete its static analysis and modal analysis through building a seamless connection between Pro/E and ANSYS Workbench. As a result, the overall deformation and static stiffness values of the manipulator arm were obtained through static analysis, and the former six-order natural frequency values and mode shapes were obtained through modal analysis. Finally, scheme of structure modification and new control method were presented by analyzing and comparing the results.

• Periodical: Applied Mechanics and Materials (Volumes 556-562)
• Pages: 1059-1064
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.556-562.1059
• Online since: May 2014
• Authors: Zhang Li*, Xi Zhe Zang, Lai Chun Suo, Yan He Zhu, Jie Zhao
• Keywords: ANSYS Workbench , Heavy-Load Manipulator Arm, Modal Analysis, Optimization, Static Analysis

References

[1] ITER Organization website. www. iter. org.

[2] Jiangang Li. Status and development of superconducting tokamak [J]. Chinese Academy of Sciences.

[3] Guangyi Pu. ANSYS Workbench12 based tutorials and examples explain [K] Beijing: China Water Power Press, (2010).

[4] Zhimin Yang, Jian Zhou, Lijun Li, Xueliang Cheng. modal analysis of picking robot arm based on ANSYS Workbench [J]. Machine Research 2013 (12).

[5] Yaodong Gao. ANSYS Workbench Mechanical engineering applications essence 30 cases [M] Beijing: Electronic Engineering Press, 2013 (3).

[6] Yongwu Chen. Modal Analysis of spraying robot based on ANSYS Workbench [J]. Behalf of machinery, 2011 (2).

[7] Ce Zhang. Mechanical dynamics [M] Beijing: Higher Education Press, (2000).

[8] Yongqiang Xiao. Optimization Design, trajectory planning and vibration suppression methods of high-speed heavy manipulator arm. [D]. Harbin: Doctoral thesis of State Key Laboratory of Robotics and System of Harbin Institute of Technology, (2012).

[9] Wei You, Minxiu Kong. Comprehensive of key technologies of control of Heavy duty industrial robot [D]. Harbin: Doctoral thesis of State Key Laboratory of Robotics and System, Harbin Institute of Technology, (2012).

[10] Xiaoqin Gu, Yanzhu Liu. Dynamics and Control Research of Space Manipulator arm [J]. Advances in Mechanics. 1997. 27 (4).

[11] Yanjun Yin. Mechanism design and optimization of the new high-speed Heavy duty aluminum ingots palletizing robot based on the fifth freedom of the hybrid mechanism [D]. Lanzhou: School of Mechanical and Electrical Engineering. Lanzhou University of Technology. (2010).
