Digital Conjugate of Tooth Surface of Logarithmic Spiral Bevel Gear

Abstract:

Based on the surface of the envelope principle and the digital conjugate surface theory, The taper logarithm helical gear meshing theory further perfect. According to the mathematical model of logarithmic spiral bevel gear tooth surface meshing, using MATLAB powerful scientific analysis and calculation visual features and functions for the conjugate tooth surface equation to get the enveloping surface discrete conjugate points and draw out the conjugate tooth surface. Again through the optimization of surface get rid of the noise, end up with conjugate tooth surface precision, and can B spline fitting. Said for further analysis of spiral bevel gear drive are very valuable.

• Periodical: Applied Mechanics and Materials (Volumes 556-562)
• Pages: 1079-1082
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.556-562.1079
• Online since: May 2014
• Authors: Qiang Li*, Yun Long Diao
• Keywords: Cone Logarithmic Spiral Bevel Gear, Conjugated Tooth Surface, Digital
