Study on the Working State of Jet-Mixing Apparatus

Abstract:

In order to study the working state of the export of jet-mixing apparatus under different loads,by comparing the bench test and its application in spray system, the working state of jet-mixing apparatus is studied.The results show that, in the bench test, the export of jet-mixing apparatus is unloaded and the state of jet-mixing apparatus is absorbing pesticide; the jet nozzle whose diameter is 2mm and suction chamber whose diameter is 3mm of the jet-mixing apparatus produce a large number of bubbles, the suction chamber emerges cavitation. The export of jet-mixing apparatus is connected with the F110 spray system, the working state of jet-mixing apparatus with a 2mm diameter jet nozzle is sucking pesticide; the working state of 3mm and 4mm jet nozzle diameter is reflux. The export of jet-mixing apparatus is connected with the outlet of F110 spray system suction chamber.They do not emerge cavitation. The load on the export of jet-mixing apparatus affect the working state of jet-mixing apparatus, also has certain influence on cavitation in the suction chamber.

• Periodical: Applied Mechanics and Materials (Volume 563)
• Pages: 219-223
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.563.219
• Online since: May 2014
• Authors: Jing Ma, Bai Jing Qiu*, Run Yan, Bei Fen Zhu
• Keywords: Backflow Condition, Cavitation, Jet-Mixing Apparatus, Suction Condition

References

[1] Langenakens J J, Climans L, Ramon H, et al. The effects of vertical sprayer boom movements on the uniformity of spray distribution[J]. Journal of Agricultural Engineering Research, 1999, 74: 281~291.

DOI: 10.1006/jaer.1999.0464

[2] Wan Peisun. The study on jet device for plant protection machinery[J]. Transaction of the Chinese Society for Agricultural Machinery, 1989, 20(3): 38~43.

[3] He Peijie, Wu Chundu, Chen Cuiying. The performance study on a new kind of spray mixing drug device[J] , Transaction of the Chinese Society for Agricultural Machinery, 2001，32（3）：44~47.

[4] Xu Youlin, Zhou Fengfang, Guo Jingkun. Flow Field Simulation of Chemical Mixing Process for Direct Injection System based on CFD[C]. 2008: ASABE International Meeting, Rhode.

DOI: 10.13031/2013.24606

[5] Qiu Baijing, Xu Xichao, Yang Ning. The simulation analysis of the influence of structure paraments on the mixing performance of jet mixing device[J], Transaction of the Chinese Society for Agricultural Machinery, 2011, 42(6): 172~174.
