Research of a New Power Quality Detection System Based on ARM

Abstract:

Based on the comparative analysis of the fast Fourier transform (FFT), the short-time Fourier transform (STFT), the wavelet transform (WT) and other power quality detection algorithms, this paper puts forward to a new power quality detection algorithm which combines the Fourier transform with the wavelet transform. The transient as well as the steady state signals are separated on the basis that the wavelet transform is sensitive to the singular signals. The presented algorithm detects a variety of harmonic parameters of the gird after the separation of steady state signals is finished by fast Fourier transform. A new power quality detection system is then designed based on the core chip of S3C2440A, and the algorithm which is ARM-9 based is transplanted into the embedded Linux operating system to carry out the experiments. Analysis of the experimental data shows the detection algorithm is reliable by Fourier transform and wavelet transform.

• Periodical: Applied Mechanics and Materials (Volumes 568-570)
• Pages: 1825-1833
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.568-570.1825
• Online since: June 2014
• Authors: Yan Qing Peng*, Feng Wang, Ji Zhang, Jia Li, Da Min Zhang
• Keywords: ARM, Fourier Transform, Linux, Power Quality, Wavelet Transform (WT)

References

[1] Jia Gao. Development of new embedded power quality monitoring system. Southeast University, Nanjing (2007). In Chinese.

[2] Yi Zhang, Yi Sun, Yu Sun. Analysis and measurement of the quality of electric energy. Measurement & Control Techniques, Vol. 12(8) (2000), pp.61-63. In Chinese.

[3] Junxia Zhang. Research and design of coal power quality online monitoring. China University of Mining & Technology, Xuzhou (2008). In Chinese.

[4] Luyan Xin: Power system harmonic analysis measurements and suppression. (Mechanical Industry Press, Beijing 1990). In Chinese.

[5] Mallat S, Hwang WL. Singularity detection and processing with wavelets. IEEE Transactions on Information Theory. Vol. 38(2) (1992), pp.617-643.

DOI: 10.1109/18.119727

[6] Jie Zhou. Research on detection and analysis system of harmonic based on ARM. Southern yangtze university, Wuxi (2008). In Chinese.

[7] Jie Shang, Hongwei Chen, Yan Li. Survey of power quality and its analytic methods. Journal of East China Shipbuilding Institute (Natural Science Edition), Vol. 16 (5) (2002), pp.83-106. In Chinese.

[8] The National Standardization Technical Committee of voltage and current level and the frequency: The frequency and power quality voltage and current National Standards Manual. (China Electric Power Press, Beijing 2001). In Chinese.
