CCD Camera Calibration Technology Based on the Translation of Coordinate Measuring Machine

Abstract:

A new CCD camera calibration method based on the translation of Coordinate Measuring Machine (CMM) is proposed. The CMM brings the CCD camera to produce the relative translation with respect to the center of the white ceramic standard sphere along the X, Y, Z axis, and the coordinates of the different positions of the calibration characteristic point in the probe coordinate system can be generated. Meanwhile, the camera captures the image of the white ceramic standard sphere at every position, and the coordinates of the calibration characteristic point in the computer frame coordinate system can be registered. The calibration mathematic model was established, and the calibration steps were given and the calibration system was set up. The comparing calibration result shows that precision of this method is equivalent to that of the special calibration method, and the difference between the calibrating data of these two methods is within ±1μm.

• Periodical: Applied Mechanics and Materials (Volumes 568-570)
• Pages: 320-325
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.568-570.320
• Online since: June 2014
• Authors: Feng Shan Huang*, Li Chen
• Keywords: Cameras Calibration, Mathematics Model, Probe Coordinate System, Translation of CMM

References

[1] LI CH Y, LI H F, SUN C H. Astronomical calibration method and observation analysis for high-accuracy star sensor[J]. Optics and Precision Engineering, 2006, 14(4): 558-563. (in chinese).

[2] WU H B, YU X Y. Structured light system model using off-the-shelf components and its calibration[J]. Optics and Precision Engineering, 2008, 16(4): 617-623. (in chinese).

[3] WU G D. Calibration of distortion for three-mirror off-axis[J]. Optics and Precision Engineering, 2008, 16(11): 2127-2131. (in Chinese).

[4] CHENG G, CHENG H, CHE R SH. Calibration method for stereo vision sensor based on spatial points[J]. Optics and Precision Engineering, 2007, 16(9): 1439-1444. (in Chinese).

[5] LIU G ZH, WANG B X, SHI H, et al. Global calibration of CCD cameras in measurement system for 3-D foot shapes[J]. Optics and Precision Engineering, 2007, 15(7): 1124 -1129. (in Chinese).

[6] WU G D, SONG D. Calibration of mapping camera and cubic prism coordinate system[J]. Optics and Precision Engineering , 2007, 15(11): 1727-1730. (in Chinese).

[7] HUANG F S , WANG CH M. Control points' light spot image recognization in light-pen vision coordinate measurement[J]. Optics and Precision Engineering, 2007, 15(4): 587-591. (in chinese).

[8] WU X B, AN W D, YANG G. Error analysing and approaches of improving measuring precision in image measuring system [J]. Optics and Precision Engineering , 1997, 5(1): 133-141. (in Chinese).

[9] LIU G X, LIN X H. Image fusion fast algorithm based on CMAC[J]. Optics and Precision Engineering , 2008, 16(5): 950-956. (in Chinese).

[10] LENZ R K, TSAI R Y. Calibrating a cartesian robot with eye-on-hand configuration independent of eye-to-hand relationship[J]. IEEE Trans, 1989, 11(9): 916-928.

DOI: 10.1109/34.35495

[11] ALF D P. System for point-by-point measuring of spatial coordinate[P]. USA: 6166809, 2000-12-26.

[12] TSAI R Y. A versatile camera calibration technique for high accuracy 3D machine vision metrology using the shelf TV camera and lenses[J]. IEEE Trans, 1987, 3(4): 323-344.

DOI: 10.1109/jra.1987.1087109

[13] Lenz R K, TSAI R Y. Techniques for calibration of the scale factor and image center for high accuracy 3D machine vision metrology[J]. IEEE Trans, 1988, 10(5): 713-720.

DOI: 10.1109/34.6781
