FEM Analysis of Sheet Incremental Forming Process

Abstract:

Sheet incremental forming is a new sheet metal dieless forming technology. This paper introduced the fundamentals of the sheet incremental forming process. Based on the principle of “layered manufacture” in rapid prototype technology, this process resolves the intricate three-dimensional geometry information of the workpiece into a series of two-dimensional data, which can be used by an NC system to control a forming tool to make a curvilinear movement over the raw sheet metal layer by layer until the component wanted is formed. This paper introduced the sheet incremental forming system and metal digital forming technology. An FEM model of the incremental forming process is established, and a typical process is analyzed to instruct the parameters selection and the optimization of the forming tracks.

• Periodical: Applied Mechanics and Materials (Volumes 571-572)
• Pages: 1079-1082
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.571-572.1079
• Online since: June 2014
• Authors: Jie Liu*
• Keywords: Dieless Forming, Finite Element Method (FEM), Sheet Incremental Forming

References

[1] Yoon SJ and Yang DY, Investigation into a new incremental forming process using an adjustable punch set for the manufacture of a doubly curved sheet metal, Proceedings of the Institution of Mechanical Engineers Part B, Journal of Engineering Manufacture, Vol. 215, Issue 7, pp.991-1004, (2001).

DOI: 10.1243/0954405011518791

[2] Z. H. Du, C. K. Chua, Y. S. Chua, K. G. Loh-Lee and S. T. Lim, Rapid Sheet Metal Manufacturing. Part 1: Indirect Rapid Tooling, International Journal of Advanced Manufacturing Technology, Vol. 19, pp.411-417, (2002).

DOI: 10.1007/s001700200042

[3] C. M. Cheah, C. K. Chua, C. W. Lee, S. T. Lim, K. H. Eu and L. T. Lin, Rapid Sheet Metal Manufacturing. Part 2: Direct Rapid Tooling, International Journal of Advanced Manufacturing Technology, Vol. 19, pp.510-515, 2002.

DOI: 10.1007/s001700200054

[4] Trent Maki. Dieless NC Forming and Sheet Fluid Forming, IMTMA Conference, Bombay, India, 11/(2002).

[5] Hiroyuki Amino, Yan Lu, et al, Dieless NC Forming, Prototype of Automotive Service Parts [A], Proceedings of the Second International Conference on Rapid Prototyping & Manufacturing, Beijing, 2002: 179-185.

[6] Matsubara S, A computer numerically controlled dieless incremental forming of a sheet metal, Proceedings of the Institution of Mechanical Engineers, Part B Journal of Engineering Manufacture, Vol. 215, Issue 7, pp.959-966, (2001).

DOI: 10.1243/0954405011518863

[7] Kochan A, Dieless forming, Assembly Automation, Vol. 21, Issue 4, pp.321-322, (2001).

[8] Iseki, H.; Shioura, T; Sato, K.; Practical Development of Process-Molding Machine with Small Punching Tool, Advanced Technology of Plasticity 1996, Proc. Of the 5th ICTP, Oct. 7-10, 1996, Columbus, Ohio USA, Vol. II, 935-938.
