Optimum Shape and Dies Design for New Thin Metal Gasket by Using Simulation Experiment

Abstract:

In this study, new thin corrugated metal gasket will be developed by using simulation experiment. The optimal design and dies design for gasket manufacturing is determined by using computer simulation based on finite element analysis (FEA). In the design stage, the Taguchi method is used to predict optimal design of new thin corrugated metal gasket. The L9 orthogonal array was concerned to design experimental matrix for four factors with three levels. In the manufacturing stage, gasket product is simulated by using ANSYS 14.5 and experimental press forming process by using press hydraulic machine. From the result, the optimal design is the model with R = 3 mm, p = 6 mm, OH = 3 mm and h = 0.2 mm. Based on simulation results and experimental press forming product, it can be concluded that the virtual design from computer simulation results can be used for predicting the real product.

• Periodical: Applied Mechanics and Materials (Volume 575)
• Pages: 271-275
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.575.271
• Online since: June 2014
• Authors: M. Agus Choiron*, Anindito Purnowidodo
• Keywords: Dies, Optimum Design, Press Forming, Simulation, Thin Corrugated Metal Gasket

References

[1] Saeed, H. A, Izumi, S., Sakai, S., Haruyama, S., Nagawa, M., Noda, H. Development of New Metallic Gasket and its Optimum Design for Leakage Performance, Journal of Solid Mechanics and Material Engineering, Vol. 2, No. 1 (2008), pp.105-114.

DOI: 10.1299/jmmp.2.105

[2] Haruyama S., Choiron M. A, Kaminishi K. A Study of Design Standard and Performance Evaluation on New Metallic Gasket, Proceeding of the 2nd International Symposium on Digital Manufacturing, Wuhan China, (2009), pp.107-113.

[3] Choiron M. A, Haruyama S., Kaminishi K., Optimum Design of New 25A-size Metal Gasket Considering Plastic Contact Stress,  International Journal of Modeling and Optimization, Vol. 1, No. 2, (2010) pp.146-150.

DOI: 10.7763/ijmo.2011.v1.26

[4] Choiron M. A, Haruyama S., Kaminishi K., Studies of Relationship between Contact Width and Leakage on Large Size of New Metal Gasket, Applied Mechanics and Materials, Vol. 229, (2012) pp.705-709.

DOI: 10.4028/www.scientific.net/amm.229-231.705

[5] M. Firat, Computer aided analysis and design of sheet metal forming processes: Part I – The Finite Element Modeling Concepts, Materials and Design 28, (2007), p.1298–1303.

DOI: 10.1016/j.matdes.2006.01.026

[6] Nurhadiyanto D., Choiron M. A, Haruyama S., Kaminishi K., Optimization of New 25A-size Metal Gasket Design Based on Contact Width Considering Forming and Contact Stress Effect, World Academy of Science, Engineering and Technology, Vol. 63 2012, (2012).

DOI: 10.7763/ijmo.2011.v1.26
