The Influence of Bolt Layout Form to the Dynamic Stiffness of the Column

Abstract:

In the case of the column materials to determined, the lower natural frequency of column is determined by the number of coupling bolts and bolt arrangement. In this paper, by three-dimensional modeling software of Solidwork column model of hobbing is set up, then by using ANSYS finite element analysis software. The initial four order natural frequency to the different number of connection bolts and the different arrangement of bolt are respectively calculated. After the initial four order natural frequency are contrasted, we conclude that in the case of merely considering dynamic stiffness this study reach it is the most reasonable to select 8-12 bolts in the hobbing of YKQ31300, and different bolt arrangement of effects on the dynamic stiffness of the column is very small and can be ignored.

• Periodical: Applied Mechanics and Materials (Volume 577)
• Pages: 222-227
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.577.222
• Online since: July 2014
• Authors: Chen Shen*, Zhong Ping Hua, Meng Sha Zhang, Zhou Zhang
• Keywords: Bolt, Column, Dynamic Stiffness, Layout Form

References

[1] Xiangyang Yan: Machinery Design Vol. 10(2011). pp.125-126. In Chinese.

[2] Shenghua Chen: Finite element analysis and optimization of the structure of CNC high-speed milling machine. Nanjing: Nanjing University of Technology, 2005, pp.35-36. In Chinese.

[3] Yuqi Wang: Main components of the finite element analysis and structure optimization design for the gear grinder of YK20100. Changsha: Central South University, 2009, pp.49-50. In Chinese.

[4] Haichang Hu: Modification restraint position on the influence of the vibration mode. Acta Mechanica Sinica Vol. 28(1996), pp.24-32. In Chinese.
