Stability Analysis of the Series-In Series Hybrid Active Power Filter

Abstract:

For the important characteristic of the system stability, a state-space averaging model of the series-in series hybrid active power filter (SHAPF) is constructed to analyze its system stability by traditional control strategy taking into account the effect of the time delay in the digital control system, inverter, low pass filter and second-order carrier-wave filter. Based on the analysis of the close-loop control model, the traditional control strategy of the series-in SHAPF is an unstable system. A new control strategy is proposed to reduce the impact of the high frequency current interference and improve its stability and filter performance of the series-in SHAPF. Validity and practicality of the proposed control strategy are proved by simulation analytical and experiment results from a 10-kW laboratory system.

• Periodical: Applied Mechanics and Materials (Volumes 58-60)
• Pages: 601-607
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.58-60.601
• Online since: June 2011
• Authors: Yao Jie Sun, Li Qing Tong, Yan Dan Lin
• Keywords: Fundamental Frequency Series-Resonance Circuit, Series-In SHAPF, State-Space Averaging

References

[1] W.M. Wu, L.Q. Tong, Z.M. Qian, et al. Analysis of a novel hybrid series active power filter topology. Proceedings of the CSEE, 2004, 24(12): 108-112.

[2] F. Z. Peng, H. Akagi, A. Nabae. A new approach to harmonic compensation in power systems-a combined system of shunt passive and series active filters. IEEE Trans. Ind. Applicat., 1990, 26(6): 983-990.

DOI: 10.1109/28.62380

[3] C. Zhong, D. H Xu. Harmonic Detection Without Delay Based on Phase Compensation of Fundamental Component. Automation of Electric Power System, 2005, 29(10): 50-54.

[4] Q.F. Chen, D. Y Li, Y. L Xiong, et al. A Series Active Power Filter with Large Capacitor. Automation of Electric Power System, 2005, 29(1): 73-76.

[5] H. H Zhong, P. P Chen, Z. Y Lu, et al. Per-phase dq Transformation Based Control Scheme for Hybrid Series Active Power Filter with Fundamental Current Bypass Channel. Automation of Electric Power System, 2004, 28(18): 63-66.

DOI: 10.1109/pesc.2004.1355557

[6] S. Srianthumrong, H. Fujita, H. Akagi. Stability analysis of a series active filter integrated with a double-series diode rectifier. IEEE PESC, 2000 3: 1305-13111.

DOI: 10.1109/pesc.2000.880498

[7] F. Z. Peng, H. Akagi, A. Nabae. Compensation characteristics of the combined system of shunt passive and series active filters. IEEE Trans. Ind. Applicat., 1993, 29(1): 144-152.

DOI: 10.1109/28.195900

[8] L. Xu, E. Acha, V. G. Agelidis. A new synchronous frame-based control strategy for a series voltage and harmonic compensator. IEEE, APEC, 2001, 2: 1274-1280.

DOI: 10.1109/apec.2001.912529

[9] G. Escobar, A.M. Stankovic, V. Cardenas, et al. A controller based on resonant filters for a series active filter used to compensate current harmonics and voltage unbalance. Proceedings of Control Applications Conf., 2002, 1: 7-12.

DOI: 10.1109/cca.2002.1040151
