The Summarization on Size Measurement of the Large Bearing

Abstract:

This paper discusses the current situation and problems of large bearing size measurement technology, and analyses the principle and the features of mechanical measurement, optical electronic measurement and modern optical measurement. Focus on the principle and the key technology of the light pen measurement as well as its application into the size measurement of the large bearings.

• Periodical: Applied Mechanics and Materials (Volumes 58-60)
• Pages: 793-798
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.58-60.793
• Online since: June 2011
• Authors: Feng Shou Zhang, Xing Xing Du, Feng Kui Cui
• Keywords: Large Bearing, Light Pen, Mechanical Measurement, Optical Electronic Measurement, Optical Measurement
