Working Performance of Anti-Arch Segments on the Left Bank Slope of Xiangjiaba Gravity Dam

Abstract:

The working performance of gravity dam with an anti-arch shape differs from that of conventional gravity dams. To understand the working performance of anti-arch segments on the bank slope of Xiangjiaba dam, linear and non-linear finite element methods were used to analyze the deformation, stress as well as the state of transverse joint and cracks during the operation period. The coefficient of anti-sliding stability of each dam segment and the safety degree of dam body were also calculated. The results show that under the conditions of non-grouting of transverse joints and well grouting of cracks, the deformation rules are consistent for all segments investigated and accord well with that of the conventional gravity dam. Both the dam heel and dam toe are subjected to compressive stress. In the cold seasons, there is a tensile stress region on the top of the dam body, where the tensile stress is smaller than the tensile strength. The transverse joints are opened, while the cracks are generally closed under compression and stable on the whole. The anti-sliding stability coefficient and the safety degree of each dam segment are above 3.0, which satisfies the design code.

• Periodical: Applied Mechanics and Materials (Volumes 580-583)
• Pages: 2063-2070
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.580-583.2063
• Online since: July 2014
• Authors: Qiu Jing Zhou*, Peng Gao, Zhao Guang Gong, Hai Feng Li
• Keywords: Anti-Arch Dam Segment, Deformation, Gravity Dam, Stress, Working Performance

References

[1] Maixing, L. D. J. Construction Technology of Heightening Project of Danjiangkou Dam for the South-to-north Water Transfer Project. Water Power, Vol. 3 (2008), p.20.

[2] Feng Shurong. General layout of Xiangjiaba Hydropower Project. Water Power, Vol, 2 (1998), p, 13.

[3] Zhou Qiujing, Yang Bo, Lian Chengzhi, etl. Influence of transverse joint grouting on working performance of xiangjiaba slope anti-arch dam blocks. Water Resources and Power, Vol, 2(2012), p, 89.

[4] Cui Jianhua, Gong Yaqi, Xiao Hanjiang. The Effect of Joint-Cutting on Turning Dam Section at the Right Bank of Danjiangkou Dam. JOURNAL of Yangtze River Scientific Research Institute, Vol, 4(2011), p, 49.

[5] Bofang, Zhu: Principle and application of finite-element method(Press of Water Conservancy and Hydropower, China 1998).

[6] Bofang, Zhu: Temperature Stress and Temperature Control of Mass Concrete(China Electric Power Press, China 1999).

[7] Chinese Design Code : Design specification for concrete gravity dams(Press of Water Conservancy and Hydropower, China 2005).

[8] Zhang Guoxin, Liu Yi, Zhou Qiujing. Study on real working performance and overload safty of high arch dam. Science in China Series E-Technological Sciences, Vol, 51(2008), p, 48.

DOI: 10.1007/s11431-008-6012-3

[9] Zhang, G. Development and application of SAPTIS-a software of multi-field simulation and nonlinear analysis of complex structures (Part I). Water Resources and Hydropower Engineering, Vol. 1(2013), p, 31.

[10] Zhou Qiujing, Zhang Guoxin. Development and application of SAPTIS-software of multi-field simulation and nonlinear analysis of complex structures(Part II). Water Resources and Hydropower Engineering, Vol. 9 (2013), p, 39.

[11] Bofang, Zhu., Chaoran, Zhang: Research on the Structural Safety of High Concrete Arch Dams(China Water Power Press, 2010).
