Mechanical Characteristics of Three-Truss Plate-Truss Composite Bridges on High-Speed Railways

Abstract:

This paper presents a study on mechanical behaviors of three-truss plate-truss composite bridges. Both a model test and numerical finite element analysis (FEA) have been conducted. The results indicate that the deck load is allocated to each truss in twice. The first allocation is among the panel points of bottom chord elements (tie beams), and the other through lateral bracings. When the stiffness of each truss (arch) is approximate, the load allocated to middle truss is about two times more than that in edge truss in the first allocation, and the second allocation makes the load tend to approximate among 3 trusses. But the vertical bending moment of bottom chord elements and the axial force of spandrel hangers in middle truss are about twice as that in the edge truss, which should be paid attention to. The results will be useful as references for design of three-truss plate-truss composite bridges.

You might also be interested in these eBooks

Innovative Solutions in the Field of Engineering Sciences

View Preview

Info:

Periodical:

Applied Mechanics and Materials (Volume 590)

Pages:

358-362

DOI:

https://doi.org/10.4028/www.scientific.net/AMM.590.358

Citation:

Cite this paper

Online since:

June 2014

Authors:

Yan Qun Han*, Mei Xin Ye

Keywords:

High-Speed Railway (HSR), Mechanical Characteristics, Three-Truss, Transverse Allocation

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

* - Corresponding Author

References

[1] Yan-qun HAN, Mei-xin YE, Ru-deng LUO. Study on the Load Transfer Routine in Truss Bridges with the Integral Deck[J]. JOURNAL OF THE CHINA RAILWAY SOCIETY, 2008, 30(1): 65-69.

Google Scholar

[2] Mei-xin YE, Feng JIANG. Study on the concrete slab-steel truss composite structures for Wuhu Yangtze River Bridge[J]. JOURNAL OF THE CHINA RAILWAY SOCIETY, 2001, 23(5): 65－69.

Google Scholar

[3] Wei HE, Qiao LI. Study on Features of Force Bearing of Plate and Truss Composite Structure System and the Calculation Method[J]. CHINA RAILWAY SCIENCE, 2001, 22(5): 65－72.

Google Scholar

[4] Ye-zhi ZHANG. Analysis on responses of continuous composite beams in high-speed railways[J]. JOURNAL OF THE CHINA RAILWAY SOCIETY, 2002, 24(6): 84－88.

Google Scholar

[5] Yu-ji CHEN, Mei-xin YE. Force of through Plate-truss Composite Beam on High-speed Railway[J]. J. CENT. SOUTH UNIV. (SCIENCE AND TECHNOLOGY), 2004, 35(5): 849－855.

Google Scholar

[6] Yan-qun HAN. The research for the mechanical characteristics and the calculating theory of three-truss plate-truss composite bridges with ballast monolithic deck of high-speed railways[D]. Changsha: School of Civil and Architectural Engineering, Central South University, (2008).
