Comparative Study on Low Voltage Ride-Through Test Methods for Grid-Connected Photovoltaic Inverter

Abstract:

The large scale photovoltaic plants have more effects on the stability of regional power grid with the rapid increase of photovoltaic generation ratio in some areas. According to the grid guideline, the photovoltaic inverter is required to maintain the running status even the grid voltage drops and needs to have the capability to contribute towards the stability of power grid voltage and to support the grid voltage ride through. To test the ability of photovoltaic inverter low voltage ride through (LVRT), the test platform to simulate all kinds of fault for voltage drop needs to be set up. By the low voltage through technical requirements, this paper puts forward three kinds of design for test platform and analyzes respective work principle and characteristics, in order to provide optimization solution for the low voltage ride through test work.
