True Stress and Shakedown Analysis of Pressure Vessel which under Cyclic Loading to Plastic Deformation

Abstract:

The aim of this study is to discuss the plastic shakedown and true stress of the cyclically loaded pressure vessel. A thin-walled cylinder pressure vessel is made according to actual working state and a water pressure test system is built. The vessel is loaded to different strain levels of plastic deformation first. Then it is loaded cyclically to shakedown state. The relationship between plastic strain and shakedown range is given based on numerous experiments. The constitutive model of the true stress-true strain of the vessel is obtained. The experimental results show that the ratcheting obviously occurred when the vessel is cyclically loaded to plastic deformation. The true stress-strain constitutive model which is presented in this paper can show appropriately the constitutive relation of the vessel when it is under multi-axial stress state. The application of uniaxial shakedown constitutive model has been demonstrated in this study.

• Periodical: Applied Mechanics and Materials (Volume 590)
• Pages: 8-12
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.590.8
• Online since: June 2014
• Authors: Xiao Liang Jia*, Yi Liang Zhang, Jing Wang, Chun Bo Wang
• Keywords: Cyclic Loading, Strain, Strain Accumulation, True Stress

References

[1] ChenGang. Numerical theories and engineering methods for structural limit and shakedown analyses. Beijing: Science Press, (2006).

[2] KANG Guo-zheng, ZHANG Juan, SUN Ya-fang, KAN Qian-hua. Uniaxial Time-Dependent Ratcheting of SS304 Stainless Steel at High Temperatures. Journal of iron and steel research, international. 2007, 14(1): 53~59.

DOI: 10.1016/s1006-706x(07)60012-0

[3] SunBingxiang. On shakedown Analysis of Thick- Wall Hollow Sphere. Journal of ShaoXing college of arts and sciences, 2000, 20(6): 74~84.

[4] DuSentian, XuBingye, PanLigong. An analysis of the shakedown problem of elasto-plastic structures under Quasi-static loading by the perturbation method. Chinese Journal Theoretical and Applied Mechanics . 1991, 23(6): 101~125.

[5] ZhengXiaotao, XuCheng, YuJiuyang, WangMingwu. Shakedown analysis of strain-hardening thin-walled cylinders considering ductile damage.J. Huazhong Univ. of Sci. & Tech, 2013, 41(9): 117~120.

[6] R. Preiss, On the shakedown analysis of nozzles using elasto-plastic FEA. International Journal of Pressure Vessels and Piping. 1999, 76(7): 421-434.

DOI: 10.1016/s0308-0161(99)00019-8
