Microstructure and Mechanical Properties of (TiAlZrNb) N Films

Abstract:

(TiAlZrNb)N hard reactive films are prepared by multi-arc ion plating technology using the combination of Ti-18Al-11Zr (at%) and Ti-25Nb (at%) alloy targets. The high speed steel (HSS) is adopted as substrate. The surface and cross-fracture morphology, the surface compositions and the phase structures of the as-deposited (TiAlZrNb)N films are observed and measured by scan electronic microscope (SEM), energy dispersive spectroscopy (EDS) and X-ray diffraction (XRD). The mechanical properties including micro-hardness, adhesion between film and substrate, friction and wear resistance and thermal shock resistance of the as-deposited (TiAlZrNb)N films are systemically investigated. The effects of deposition bias voltage and the addition of Nb element on the as-deposited (TiAlZrNb)N films are discussed. It is revealed that the comprehensive performances including micro-hardness, adhesion and friction resistance can be achieved by the (TiAlZrNb)N hard reactive film with deposition bias voltage of 150V.

• Periodical: Applied Mechanics and Materials (Volume 590)
• Pages: 86-90
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.590.86
• Online since: June 2014
• Authors: Jian Zhang, Jun Zhang*, Wei Zhao
• Keywords: (TiAlZrNb)N Film, Adhesion, Friction Resistance, Hardness, Thermal Shock, Wear Resistance

References

[1] J. Zhang, H. M. Lv, G.Y. Cui, Effects of bias voltage on the microstructure and mechanical properties of (Ti, Al, Cr) N hard films with N-gradient distributions, Thin Solid Films, 519(2011) 4818-4823.

DOI: 10.1016/j.tsf.2011.01.036

[2] K. Vasu,M. Ghanashyam Krishna, K.A. Padmanabhan, Effect of Nb concentration on the structure, mechanical, optical and electrical properties of nanocrystalline Ti1-xNbxN thin films, J Mater Sci, 47(2012) 3522-3525.

DOI: 10.1007/s10853-011-6197-x

[3] A.P. Serro, C. Completo, R. Colaco, F Dos Santos, C Lobato da Silva, JMS Cabral, H Araújo, E Pires, B Saramago A comparative study of titanium nitrides, TiN, TiNbN and TiCN, as coatings for biomedical applications, Surface & Coatings Technology, 203(2009).

DOI: 10.1016/j.surfcoat.2009.06.010

[4] H.Y. Zhang, L.Y. Zhou, J.C. Tian, Effect of Substrate-b ias on the Characteristic of TiAlN Coatings, Surface Technology, 35(2006) 15-16.

[5] J. Zhang, W. Y. Guo, Y. Zhang, Mechanical properties and phase structure of (TiAlZr)N films deposited by multi arc ion plating , Thin Solid Films, 517（2009）4830-4834.

DOI: 10.1016/j.tsf.2009.03.051

[6] H. Hasegawa, A. Kimura, T. Suzuki, Microhardness and structural analysis of (Ti, Al)N, (Ti, Cr)N, (Ti, Zr)N and (Ti, V)N films, J. Vac. Sci., Technol., A18 (2000) 1038-1040.

DOI: 10.1116/1.582296
