A Theoretical Study of the Phase Angle for the β Type Pulse-Steam Stirling Expander

Abstract:

This paper introduces a small steam expander linked to a moderate/small industrial steam boiler to form a small scale cogeneration system for the purpose of energy conservation and carbon-emission reduction. Here, a traditional regulator will be replaced by the steam expander. In order to effectively extract the high pressure steam’s unused energy (flow energy) from the boiler, the steam will be induced into an expanding process. Here, a Pulse-Steam Stirling Expander (PSSE), which is different from a normal steam expander, is proposed in the study. In order to decrease the steam condensation and increase the overall output power, the PSSE expander adopts an isothermal process instead of the traditional isentropic process. The PSSE cycle, which is composed of an isothermal process and an isovolumetric process, is similar to the Stirling cycle. Therefore, considering the influence of the valve’s opening/closing within the PSSE cycle and adopting the Stirling engine’s Schmidt theory, the mathematical model of the PSSE cycle has been established. The characteristic analysis of the PSSE expander has been assessed based on the mathematical model. Moreover, a prototype of the PSSE expander has been constructed and tested. According to theoretical analysis and experimental data, the output power for the PSSE expander is closely related to the phase angle between the displacer and the piston. Consequently, the mathematical model of the PSSE expander proposed in this study can be applied to design the practical PSSE expander in industry.

• Periodical: Applied Mechanics and Materials (Volume 597)
• Pages: 425-430
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.597.425
• Online since: July 2014
• Authors: Guang Jer Lai, C.K. Lin, Yoshiyuki Kobayashi, Masahiro Matsuo, Min Chie Chiu*
• Keywords: Phase angle, Pulse Steam Expander, Stirling Engine

References

[1] T. Brookes, CO2 Powered Model Aircraft, Nexus Special Interests, (2002).

[2] Kobayashi Yoshiyuki, Model steam rankine Stirling engine for educational use, The Symposium on Stirlling Cycle 12 (2009) 83-84.

DOI: 10.1299/jsmessc.2009.12.83

[3] G. Walker, Stirling Engines, Oxford Univ. Press, (1980).

[4] D.G. Thombare, S.K. Verma, Technological development in the Stirling cycle engines, Renewable & Sustainable Energy Reviews 12(1) (2008) 1-38.

DOI: 10.1016/j.rser.2006.07.001
