Fault Diagnosis of Mechanized Bridge’s Electrical System Based on I²C-bus and Virtual Instrument Technology

Abstract:

The electrical system fault testing and diagnosis system based on I²C-bus and embedded equipment is proposed. This system is accomplished with the integration of PXI-based computer, field fault testing platform, dedicated interface adapter unit and accessories with software program of virtual instrument and database management and fault guidance system. It can obtain various state parameters of the heavy mechanized bridge by interface adapter unit and corresponding sensors. The dedicated interface adapter unit, that is the core of the hardware platform is composed of chassis, embedded microcomputer controller, I²C-bus data acquisition modules, VPC connection package and military aviation sockets. Because of its flexibility and modular design, it can support different data conversion, for example, analog, digital, and serial, while functioning as an intelligent conversion bridge between field fault testing platform or PXI computer and electrical system of heavy mechanized bridge electrical system. The fault diagnosis software is of hierarchical modular structure with integration of system management control, fault detection and circuit hardware driver modules together with fault repair and diagnosis database. Therefore it provides functions of human-machine interaction, equipment fault detection, fault diagnosis and analysis, as well as repair and maintenance guidance The fault testing and diagnosis system in this work is also featured with handy structure, lightweight, low consumption, large storage capacity, excellent expandability and intelligent inference capability. The system can be used in the online fault testing and diagnosis of similar engineering equipments. So it has important engineering and military application value to the rapid fault testing and fault diagnosis of engineering equipments.

• Periodical: Applied Mechanics and Materials (Volume 597)
• Pages: 444-449
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.597.444
• Online since: July 2014
• Authors: Yong Sheng Sun, Xiao Qiang Yang*, Li Pei, Sun Yan
• Keywords: Dedicated Interface Adapter, Embedded Equipment, Fault Diagnosis, I2C Bus, Mechanized Bridge

References

[1] L.B. Jack, A.K. Nandi. Fault Detection Using Support Vector Machines and Artificial Neural Networdks Augmented by Gentic Algorithms. Mechanical Systems and Signal Processing, Volume 16, Issues 2-3, March 2002, 373-390.

DOI: 10.1006/mssp.2001.1454

[2] L Gonzálezf1, I Anderson, D Deane, C Summers, D Buxton. Detection of Immune System Cells in Paraffin Wax-embedded Ovine Tissues. Journal of Comparative Pathology, Volume 125, Issue 1, July 2001, 41-47.

DOI: 10.1053/jcpa.2001.0475

[3] Paul Kocher, Ruby Lee, Gary McGraw, Anand Raghunathan. Security as a new dimension in embedded system design. Proceedings of the 41st annual Design Automation Conference, ACM New York, NY, USA @(2004).

DOI: 10.1145/996566.996771

[4] Rolf Isermann. Model-based fault-detection and diagnosis – status and applications, Annual Reviews in Control, Volume 29, Issue 1, 2005, 71-85.

DOI: 10.1016/j.arcontrol.2004.12.002

[5] Rolf Isermann. Supervision, fault-detection and fault-diagnosis methods — An introduction, Control Engineering Practice, Volume 5, Issue 5, May 1997, 639-652.

DOI: 10.1016/s0967-0661(97)00046-4

[6] Samuel R. Madden, Michael J. Franklin, Joseph M. Hellerstein, Wei Hong. an acquisitional query processing system for sensor networks. ACM Transactions on Database Systems, Volume 30 Issue 1, 1324-1339，March (2005).

DOI: 10.1145/1061318.1061322
