The Model Establishment and Simulation Analysis of Controllable Pendulum

Abstract:

Indicating vertical in moving base to establish horizontal reference is of great significance for the near-earth autonomous navigation. Existing vertical indicating device achieves the goal by using gyro stabilized platform, but the gyroscope is difficult to maintain and has drift error. This paper proposes controllable pendulum system that is a stable closed-loop control system and similar to inverted pendulum system to accomplish the purpose. This paper covers the preliminary validation of the controllable system’s ability of indicating vertical in pulse interference cases and raises the defects of system under condition of step disturbance, by establishing mathematical model, designing double output PID controller and analyzing error , which lays the foundation for follow-up study.

• Periodical: Applied Mechanics and Materials (Volumes 599-601)
• Pages: 714-717
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.599-601.714
• Online since: August 2014
• Authors: Fan Li*, Geng Biao Shen, Zi Chao Zhang, Jian Hui Zhao
• Keywords: Controllable Pendulum, Dual Outputs PID Controller, MATLAB/SIMULINK

References

[1] Zi-Chao Zhang. Research on vertical-orienting control of controllable pendulum with moving base[D]. Beijing: Beijing University of Aeronautics and Astronautics, (2011).

[2] Cai Z W, Liu D C, Zhang X H. A First-order Inverted Pendulum Double Closed Loop Control Method Based on Robust Design[J]. Techniques of Automation and Application, 2004, 23 (4): 11-15.

[3] Wang Yong Guang. Control Methods Research on Inverted Pendulum System[D]. Xi-an: Xi 'an University of Electronic Science and Technology, (2009).

[4] Luo Jing, Chen Pin. PID Control of The First-order Inverted Pendulum[J]. Research and Exploration in Laboratory, 2005, 24 (11): 26-28.

[5] Wu Shan Yong. Control Algorithm Research on Inverted Pendulum[D]. Xi 'an University of Electronic Science and Technology, (2009).
